ASUS GeForce RTX 5060 Ti Prime OC 8GB GDDR7 Graphics Card

  • Part Number: 90YV0MP0-M0NA00
  • Manufacturer: ASUS
  • Quickfind Code: 125821
  • Stock: In Stock

£361.89 ex. vat
£434.27 inc. vat

Product Features:
  • Condition: New
  • GPU RTX 5060 Ti
  • Capacity 8GB
  • Connection PCI-E
  • Memory Type GDDR7
  • Series RTX
  • GPU Manufacturer Nvidia
+ Read More Information

Share:

Product Description

Experience Primal performance with the Prime GeForce RTX 5060 Ti, an SFF-Ready Enthusiast GeForce Card featuring a 2.5-slot design for expansive compatibility, enhanced by a triple-fan setup for supreme airflow design for supreme cooling.

Main Features

  • AI Performance: 772 AI TOPS
  • OC Edition: 2647 MHz OC mode, 2617 MHz default mode
  • Powered by the NVIDIA Blackwell architecture and DLSS 4
  • SFF-Ready Enthusiast GeForce Card
  • Axial-tech fans feature a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure
  • 2.5-slot design allows for greater build compatibility while maintaining cooling performance
  • Dual-ball fan bearings last up to twice as long as standard sleeve bearings
  • 0dB technology lets you enjoy light gaming in relative silence
  • Dual BIOS switch lets you toggle between Quiet and Performance BIOS profiles
  • Auto-Extreme manufacturing process for precision and reliability
  • GPU Tweak III software provides intuitive performance tweaking, advanced thermal control and system monitoring
Technical Specification

ASUS GeForce RTX 5060 Ti Prime OC 8GB GDDR7 Graphics Card

GPU

Chipset ManufacturerNVIDIA
Chipset Model NameGeForce RTX
Chipset Model Number5060 Ti
Chipset Additional InformationPrime OC
Boost Chip Clock2617 MHz
Graphics CoreCUDA
Number of Cores4608

Memory

Memory Size8192 MB
Memory Clock28 Gbps
Memory TypeGDDR7
Memory Width128 bit
Memory Bandwidth448 GB/s

Interfaces/Ports

Video Card Bus TypePCI Express
Video Card Bus Version5.0 x8
HDMI Port1 x HDMI 2.1b
DisplayPort3 x DisplayPort 2.1b

Resolution

Multiple Monitor Support (Max)Yes (4)
Maximum Resolution7680 x 4320

System Requirements

System Requirements1 x PCI Express 5.0 x16 slot

Electrical

Power Connector1 x 8-pin PCIe
Power Consumption180 W
Recomended Power Supply550 W

Physical

Form FactorGraphics Card
In The BoxGraphics Card
Speedsetup Manual
ASUS Velcro Hook & Loop
Thank You Card
Width50 mm (2.5 slot)
Depth304 mm
Height120 mm

Warranty

Warranty3 Years

Key Features

Interface TypePCI Express 5.0 x8
Graphics Memory TypeGDDR7
Main ColourBlack
VGA ConnectionNo
DVI ConnectionNo
HDMI ConnectionYes
Graphics UsabilityGaming
DisplayPort ConnectionYes
Direct X SupportDirect X 12
Cooler TypeDynamic Fan Inc. 0dB Mode
Low ProfileNo
NVIDIA GeForceRTX 5060 Ti
PCIe Pin Type6+2-Pin
Cooling TechnologyDynamic Fan Inc. 0dB Mode
VR ReadyNVIDIA
GPU Length304 mm
Card Width3
Power Requirement (auto)180 W
GPU Power (TDP)180 W
Graphics card count1
PCIe Physical Slot required16
12VHPWR 16-pin ConnectorNo
AI ReadyYes

Graphics

Graphics ChipsetGeForce RTX 5060 Ti

Graphics Device

G-SyncYes

Item Details

ManufacturerASUS
Manufacturer Code90YV0MP0-M0NA00
EAN4711387994207
