Fractal Design Meshify 2 Nano ITX Case White

Part Number: FD-C-MES2N-02
Manufacturer: Fractal Design
Quickfind Code: 105534

Stock: Out Stock

Contact for availability

Product Features:

Condition: New
Form Factor ITX
Main Colour White
Side Panel Tempered Glass

+ Read More Information

Product Description

The Meshify 2 Nano offers ITX form-factor enthusiasts plenty of scope for creative builds through excellent radiator support for its size and the ability to accommodate a GPU of up to 331 mm. It also features a fully removable top, bolt-free side panels and a removable front mesh to make building and cable routing easy and enjoyable. The flexible design and angular asymmetry are complemented by a flush TG panel to showcase your finished build.

Main Features

Compact yet spacious interior accommodates all Mini ITX motherboards
Iconic angular mesh front provides filtered airflow with a bold, stealth-inspired aesthetic
Open interior layout creates a smooth airflow path from front intake to rear exhaust
Room for GPUs up to 306 mm long including front fans with 331 mm total space
Seamlessly integrated TG panel with steel frame support and bolt-free top-latching mechanism
Fully removable top panel and a top fan bracket that opens to provide excellent interior access and easy cable routing
Double layered front filter with detachable nylon for increased airflow
Three front USB ports including one USB Type-C with fast charging and speeds up to 10Gbps
Front panel design with hinged removable mesh and tether-free bezel for easier access to front fan mounts
Flexible storage option supporting one 3.5" drive and three 2.5" drives
Install up to 6x 120 mm or 3x 140 mm fans
Pre-installed Dynamic X2 1x 120 mm and 1x 140 mm fans ensure smooth airflow with minimal noise
Easy-to-clean filters on the front, top and base with full PSU coverage and convenient front access
Bridgeless PCI expansion slots ensure obstruction-free connections for easier installation and hookup
Ventilated PSU shroud with two-part modular air duct for increased GPU airflow and radiator support
Integrated cable guides with cable straps further simplify cable management behind the board

Technical Specification

Fractal Design Meshify 2 Nano ITX Case White

User Controls

Power

Storage

Internal Expansion Bays

2 x 2.5"
1 x 3.5"

Expansion

Expansion Slots

2 x Full Height

Interfaces/Ports

USB Ports	1 x USB-C 3.1 2 x USB 3.0 2 x USB 2.0
Headphone Ports	1 x 3.5mm Jack
Microphone In Port	1 x 3.5mm Jack

Electrical

Cooling System	Front: Supports 2 x 140mm or 120mm fans (1 x 140mm fan included) Top: Supports 2 x 120mm fans Rear: Supports 1 x 120mm fan
Power Supply	ATX Power Supply supported

Physical

Form Factor	Mini Tower Case
Case Colour	White
Motherboard Compatibility	Mini-ITX Mini-DTX
In The Box	Case User Manual Accessory Box
Width	205 mm
Depth	396 mm
Height	361 mm
Weight	5.9 kg

Warranty

2 Years

Key Features

Firewire
Power	W
Laptop Size Range	ins
Main Colour	White
External Expansion Bays
Case Type	SFF
USB 3.0 Support	Yes
Case Form Factor	ITX
Power Supply Included	No
Optimised for
Modular Cables
80Plus Rated	No
Bag Size
PSU Form Factor	ATX
Display Model in Showroom
Illuminated	No
e-SATA
L.E.D Fan	No LED
Laptop Size
Max 3.5" Drives	1
Max 2.5" Drives	2
ATX
Micro-ATX
ITX	Yes
E-ATX
XL-ATX
Mini PC
Cooler Height	167 mm
Built-in Card Reader	No
USB Type-C Support	Yes
Front HDMI	No
Side Panel Type	Tempered Glass
GPU Length	306 mm
PSU Depth	165 mm
Memory Speed	MHz
Card Reader Type
Front Audio Type	Separate
Number of Fans	2 fan(s)
LED Controller Included	No
LED Strip(s) Included
Maximum Motherboard Size Supported	ITX
RGB Software Type
Total 2.5" + 3.5" drive bays	3
Power Requirement (auto)	6 W
USB2.0 ports	2
USB3.0 ports	2
USB-C ports	1
Low profile expansion	No
