LCD panel type | IPS technology |
Backlight type | W-LED system |
Panel Size | 23.8 inch/60.5 cm |
Display Screen Coating | Anti-Glare, 3H, Haze 25% |
Effective viewing area | 527 (H) x 296.5 (V) |
Aspect ratio | 16:9 |
Optimum resolution | 1920 x 1080 @ 60 Hz |
Pixel Density | 93 PPI |
Response time (typical) | 5 ms (Grey to Grey)* |
Brightness | 250 |
Contrast ratio (typical) | 1000:1 |
SmartContrast | 50,000,000:1 |
Pixel pitch | 0.275 x 0.275 mm |
Viewing Angle | 178º (H)/178º (V); @ C/R > 10 |
Viewing angle | 178º (H)/178º (V) |
Viewing angle | @ C/R > 10 |
Scanning Frequency | 30–85 kHz (H) / 48–75 Hz (V) |
Flicker-free | Yes |
Picture enhancement | SmartImage |
Colour gamut (typical) | NTSC 89.9%*, sRGB 103.8%* |
Display colours | 16.7 M |
Scanning Frequency | 30–85 kHz (H)/48–76 Hz (V) |
sRGB | Yes |
EasyRead | Yes |
Signal input | VGA (Analogue); DVI-D (digital, HDCP); DisplayPort 1.2; HDMI 1.4 |
LowBlue Mode | Yes |
Audio (In/Out) | PC audio-in; Headphone out |
Adaptive sync | Yes |
Signal Input | VGA (Analogue) |
User convenience | SmartImage; Input; Brightness; Menu; Power On/Off |
Signal Input | DVI-D (digital, HDCP) |
OSD languages | Brazil Portuguese; Czech; Dutch; English; Finnish; French; German; Greek; Hungarian; Italian; Japanese; Korean; Polish; Portuguese; Russian; Simplified Chinese; Spanish; Swedish; Traditional Chinese; Turkish; Ukrainian |
Signal Input | DisplayPort 1.2 |
Other convenience | Kensington lock; VESA mount (100 x 100 mm) |
Signal Input | HDMI 1.4 |
Plug and Play Compatibility | DDC/CI; Mac OS X; sRGB; Windows 10 / 8.1 / 8 / 7 |
USB | USB 3.0 x 2 (1 w/fast charging)* |
USB | USB 2.0 x 2 |
Audio (In/Out) | PC audio-in |
Audio (In/Out) | Headphone out |
Sync Input | Separate Sync |
Sync Input | Sync on Green |
On mode | 14.21 W (typ.) (EnergyStar test method) |
Built-in Speakers | 2 W x 2 |
Standy mode | < 0.5 W (typ.) |
User convenience | SmartImage |
User convenience | Input |
Power LED indicator | Operation - White; Standby mode - White (flashing) |
User convenience | Brightness |
Power supply | Built-in; 100–240 VAC, 50–60 Hz |
User convenience | Menu |
User convenience | Power On/Off |
Control software | SmartControl |
OSD Languages | Brazil Portuguese |
Packaging in mm ( W x H x D) | 600 x 468 x 198 |
OSD Languages | Czech |
OSD Languages | Dutch |
OSD Languages | English |
OSD Languages | Finnish |
OSD Languages | French |
OSD Languages | German |
Relative humidity | 20%-80 |
OSD Languages | Greek |
OSD Languages | Hungarian |
OSD Languages | Italian |
Environmental and energy | EnergyStar 8.0; EPEAT*; TCO Certified Edge; RoHS; WEEE |
OSD Languages | Japanese |
OSD Languages | Korean |
Specific Substances | PVC/BFR free housing; Mercury free |
OSD Languages | Polish |
OSD Languages | Portuguese |
OSD Languages | Russian |
OSD Languages | Simplified Chinese |
OSD Languages | Spanish |
OSD Languages | Swedish |
OSD Languages | Traditional Chinese |
OSD Languages | Turkish |
OSD Languages | Ukrainian |
Other convenience | Kensington lock |
Other convenience | VESA mount (100 x 100 mm) |
Plug and Play Compatibility | DDC/CI |
Plug and Play Compatibility | Mac OS X |
Plug and Play Compatibility | sRGB |
Plug and Play Compatibility | Windows 10 / 8.1 / 8 / 7 |
Height adjustment | 150 |
Pivot | -/+ 90 degree |
Swivel | -175/175 |
Tilt | -5/30 |
ECO mode | 10 W (typ.) |
On mode | 13 W (typ.) (EnergyStar 7.0 test method) |
Standby mode | < 0.5 W (typ.) |
Off mode | Zero watts with Zero switch |
Energy Label Class | A+ |
Power LED indicator | Operation - White |
Power LED indicator | Standby mode - White (flashing) |
Power supply | Built-in |
Power supply | 100-240 VAC, 50-60 Hz |
Product with stand (max height) | 540 x 508 x 206 |
Product without stand (mm) | 540 x 323 x 50 |
Packaging in mm (W x H x D) | 600 x 468 x 198 |
Product with stand (kg) | 4.97 |
Product without stand (kg) | 3.37 |
Product with packaging (kg) | 7.17 |
Temperature range (operation) | 0°C to 40°C |
Temperature range (storage) | -20°C to 60°C |
Relative humidity | 20%–80% |
Altitude | Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m) |
MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
Environmental and energy | EnergyStar 7.0 |
Environmental and energy | EPEAT Gold* |
Environmental and energy | TCO edge |
Environmental and energy | RoHS |
Environmental and energy | WEEE |
Recyclable packaging material | 100 |
Post-consumer recycled plastic | 85% |
Specific Substances | PVC/BFR free housing |
Specific Substances | Mercury free |
Specific Substances | Lead free |
Regulatory Approvals | CE Mark |
Regulatory Approvals | CB |
Regulatory Approvals | EPA |
Regulatory Approvals | FCC Class B |
Regulatory Approvals | SEMKO |
Regulatory Approvals | cETLus |
Regulatory Approvals | UKRAINIAN |
Regulatory Approvals | ICES-003 |
Regulatory Approvals | TUV/GS |
Regulatory Approvals | TUV Ergo |
Regulatory Approvals | PSE |
Regulatory Approvals | PSB |
Regulatory Approvals | MEPS |
Regulatory Approvals | CU-EAC |
Regulatory Approvals | VCCI |
Regulatory Approvals | RCM |
Regulatory Approvals | J-MOSS |
Front bezel | Black |
Rear cover | Black |
Foot | Black |
Finish | Texture |
Monitor with stand | Yes |
Cables | D-Sub cable, HDMI cable, DP cable, Audio cable, Power cable |
User Documentation | Yes |
