Technical Specification
iiyama G-MASTER GB2470HSU-W6 Red Eagle 23.8" 180HZ IPS Gaming Monitor White
Specifications
Display Characteristics:
Diagonal
23.8", 60.5cm
Panel
Fast IPS
Native resolution
1920 x 1080 @180Hz (2.1 megapixel Full HD, DisplayPort)
Aspect ratio
16:9
Panel brightness
300 cd/m²
Static contrast
1000:1
Advanced contrast
80M:1
Response time (MPRT)
0.2ms
Viewing zone
horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Colour support
16.7mln 8bit
Horizontal Sync
30 - 225kHz
Viewable area W x H
527 x 296.5mm, 20.7 x 11.7"
Pixel pitch
0.275mm
Colour
matte, white
Interfaces / Connectors / Controls
Blue light reducer
yes
Flicker free
yes
Adaptive Sync support
HDMI: 1920 x 1080 @48-180Hz, DP: 1920 x 1080 @48-180Hz
Extra
i-Style Colour
OSD languages
EN, DE, FR, ES, IT, PT, RU, JP, CZ, NL, PL
Control buttons
Signal select/ Exit, + / Volume, - / i-Style Colour, Menu, Power
User controls
picture adjust (contrast, brightness, OD, ACR, ECO, Black Tuner, MBR, gamma), input select (input source), audio adjust (volume, mute), store user settings (user modes), colour settings (colour temperature, 6-Axis, user preset), image adjust (i-Style colour, X-Res Technology, sharp & soft, HDMI range, direct drive mode, video mode adjust), language, setup menu (OSD H. position, OSD V. position, OSD time, opening logo, OSD rotate, Adaptive Sync, LED, DDC/CI, USB BC), display information, reset
Speakers
2 x 2W
Convenience
Kensington-lock prepared, DDC2B, Mac OSX
Mechanical
Display position adjustments
swivel, tilt, pivot (rotation both sides)
Height adjustment
150mm
Rotation (PIVOT function)
90°
Swivel stand
90°; 45° left; 45° right
Tilt angle
23° up; 5° down
VESA mounting
100 x 100mm
Cable management system
yes
Accessories
Cables
power, USB, HDMI, DP
Other
quick start guide, safety guide
Power Management
Power supply unit
internal
