Specification
Display
Diagonal
23.8", 60.5cm
Panel
IPS, matte finish
Native Resolution
1920 x 1080 @144Hz
Aspect Ratio
16:9
Panel Brightness
350 cd/m²
Static Contrast
1500:1
Advanced Contrast
80M:1
Response Time (MPRT)
1ms
Viewing Zone
horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Colour Support
16.7mln
Horizontal Sync
30 - 163kHz
Viewable Area (W x H)
527 x 296.5mm, 20.7 x 11.7"
Pixel Pitch
0.2745mm
Colour
matte, black
Interfaces / Connectors / Controls
Signal Input
HDMI x1 (v.1.4)
DisplayPort x1 (v.1.2)
USB HUB
x2 (v.2.0 DC5V, 500mA)
HDCP
yes
Headphone Connector
yes
Features
Blue Light Reducer
yes
Flicker Free
yes
Adaptive Sync Support
FreeSync - 1920 x 1080 @48-144Hz
OSD languages
EN, DE, FR, ES, IT, RU, JP, CZ, NL, PL
Control Buttons
Joystick / Power Button: Power / Menu (Center), Up / Input Select, Down, Right / Volume / Mute Audio, Left / Brightness / Adaptive Sync / Night Mode / Motion Blur Reduction / i-Style Colour / ECO
User Controls
picture adjust (contrast, brightness, OD, Adaptive Sync, Adv. Contrast, Night Mode, Motion Blur Reduction, Gamma), input select (Auto/Manual, HDMI, DP), audio settings (volume, mute audio), store user settings (user modes), colour settings (6-Axis, colour temperature, user preset, i-style colour, blue light reducer, black tuner), image adjust (sharpness, RGB range, video mode adjust, x-res technology), language, setup menu (OSD h. position, OSD v. position, OSD time, OSD background, OSD rotate, opening logo, power LED, ddc/ci control), display information, reset (reset all)
Speakers
2 x 2W
Convenience
Kensington-lock™ prepared, DDC/CI, DDC2B, Mac OSX
Mechanical
Display Position Adjustments
tilt
Tilt Angle
22° up; 4° down
VESA Mounting
100 x 100 mm
Cable Management System
yes
Accessories Included
Cables
power (1.5m), USB (1.5m), HDMI (1.5m)
Other
quick start guide, safety guide
Power Management
Power Supply Unit
internal
Power Supply
AC 100 - 240V, 50/60Hz
Power Usage
17W typical, 0.5W stand by, 0.3W off mode
Sustainability
Regulations
CE, TUV-Bauart, EAC, VCCI-B, PSE, RoHS support, ErP, WEEE, REACH, UKCA
Energy Efficiency Class (Regulation (EU) 2017/1369)
C
REACH SVHC
above 0.1%: Lead
Weight & Dimensions
Product Dimensions (W x H x D)
539 x 391.5 x 349mm
Box Dimensions (W x H x D)
615 x 395 x 126mm
Weight (without box)
3.3 kg
Weight (with box)
4.4 kg
