MSI Z390-A PRO Intel Socket 1151 Motherboard

£159.99 ex. vat
£191.99 inc. vat

Supports 9th / 8th Gen Intel® Core™ / Pentium® Celeron® processors for LGA 1151 socket
Supports DDR4 Memory, up to 4400(OC) MHz
Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.
Set Core Power Free: Core Boost, 8+4 pin CPU power connector, Core Boost, DDR4 Boost
Audio Boost: Reward your ears with studio grade sound quality.
Extended Heatsink Design: MSI extended PWM and enhanced circuit design ensures even high-end processors to run in full speed.
Intel® LAN:Premium network solution from Intel® for professional and multimedia use. Delivers a secure, stable and fast network connection.
Multi-GPU: With Steel armor PCI-E slots. Supports 2-Way AMD Crossfire™
Intel Turbo USB 3.1 Gen2: Powered by Intel USB 3.1 Gen2 controller, Turbo USB ensures an uninterrupted connection with more stability and fastest USB speeds

CPU

CPU Socket	Socket 1151
CPU Brand	Intel
Installed Processors (Max)	0 (1)
Supported Processor Manufacturer	Intel
Supported Processors	9th/ 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors
64-bit Support	Yes
Socket	LGA1151

Rear Panel I/O Ports

USB Ports	1 x USB 3.1 Type-C 1 x USB 3.1 Type-A 2 x USB 3.0 2 x USB 2.0
DisplayPorts	1 x DisplayPort
VGA Port	1 x D-Sub
Keyboard/Mouse Combo Port	1 x PS/2
RJ-45 Ports	1 x RJ-45
Digital Port	1 x DVI-D
Audio Line In Ports	1 x 3.5mm Jack
Audio Line Out Ports	4 x 3.5mm Jacks
Microphone In Port	1 x 3.5mm Jack

Internal I/O Connectors

SATA Connectors	6 x SATA III
USB Connectors	2 x USB 3.0 2 x USB 2.0
Front Panel Connectors	1 x Front Panel 1 x Front Audio
Cooling Fan Support	1 x CPU fan 1 x Water Pump 5 x System fans
Thunderbolt Port(s)	1 x Thunderbolt™ AIC connector
Parallel Connectors	1 x Parallel
Serial Connectors	1 x COM
Chassis Intrusion Connector	1 x Chassis Intrusion
TPM Header	1 x TPM
Power Connector Port	1 x 20+4-pin ATX 1 x 4+4-pin EPS 1 x 6-pin PCIe
Other Connectors	1 x M.2, Key M (Type 2242/2260/2280/22110) 1 x M.2, Key E (Type 2230) for Wi-Fi Module 1 x RGB LED header

Memory

Memory Bus Speed	4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) / 2800(OC)/ 2666/ 2400/ 2133 MHz
Memory Type	DDR4
Maximum RAM	64 GB
Memory Slot	4 x DIMM

Motherboard

Expansion

Number of PCI Express Slots

2 x PCI Express 3.0 x16
4 x PCI Express 3.0 x1

Graphics Device

Integrated Graphics Supported

Yes

Sound

Integrated Sound

Realtek® ALC892

Network

System Requirements

Operating Systems Supported

Microsoft® Windows® 10 64-bit

System

Jumpers	1 x Clear CMOS
Drivers	Included
SLi/Crossfire Features	Supports 2-Way AMD® CrossFire™ Technology

Physical

Form Factor	ATX Motherboard
In The Box	MSI Z390-A PRO Motherboard Quick Installation Guide Warranty Card 2 x SATA Cables Support DVD I/O Shield
Width	305 mm
Length	244 mm

Key Features

M.2 Support	Yes
On-board RGB Control	None
Memory Speed	4400 MHz
Skip Audio Test	No
RGB Header Type	None
Addressable RGB	No
Firewire	No
Wireless Network	No
Main Colour	Black
Socket(s)	LGA 1151
Memory Channel	Dual
On-board Audio Type	7.1
Number of SATA Ports	6 port(s)
Number of USB Ports	6 port(s)
SATA III Support	Yes
USB 3.0 Support	Yes
Multi GPU Support	ATi CrossFire
VGA Connection	Yes
DVI Connection	Yes
HDMI Connection	No
DisplayPort Connection	Yes
Motherboard Form Factor	ATX
Motherboard Power Connectors	4 + 4-Pin
Motherboard Chipset	Intel Z390
Thunderbolt	No
Motherboard Model	MSI Z390-A PRO
USB 3.1 Support	Yes
Internal USB3.0 Header	Yes
