ASUS ROG Strix Z590-I Gaming WiFi Intel Socket 1200 Z590 Chipset Mini-ITX Motherboard
ASUS ROG Strix Z590-I Gaming WiFi Motherboard
CPU
| CPU Socket | Socket 1200 |
| CPU Brand | Intel |
| Installed Processors (Max) | 0 (1) |
| Supported Processor Manufacturer | Intel |
| Supported Processors | 11th Gen Intel Core processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors |
| 64-bit Support | Yes |
| Socket | LGA1200 |
Rear Panel I/O Ports
| USB Ports | 1 x Thunderbolt 4 1 x USB 3.2 Type-C 1 x USB 3.1 1 x USB 3.0 4 x USB 2.0 |
| HDMI Port | 1 x HDMI 2.0 |
| RJ-45 Ports | 1 x RJ-45 |
| Audio Line In Ports | 1 x 3.5mm Jack |
| Audio Line Out Ports | 1 x 3.5mm Jack |
| Microphone In Port | 1 x 3.5mm Jack |
| Antenna Connector(s) | 2 x SMA Antenna |
Internal I/O Connectors
| SATA Connectors | 4 x SATA III |
| USB Connectors | 1 x USB 3.1 Type-C header (supports 1 port) 1 x USB 3.0 header (supports 2 ports) 1 x USB 2.0 header (supports 2 ports) |
| Speaker | 1 x Speaker header |
| Front Panel Connectors | 1 x Front Panel 1 x Front Audio |
| Cooling Fan Support | 1 x CPU fan header 1 x AIO Pump header 1 x Chassis fan header |
| Power Connector Port | 1 x 20+4-pin ATX 1 x 8-pin EPS |
| Other Connectors | 2 x M.2, Key M, Type 2242/2260/2280 1 x 3-pin ARGB LED header 1 x 4-pin RGB LED header 1 x Thermal Sensor header |
Memory
| Memory Bus Speed | 5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz |
| Memory Type | DDR4 |
| Maximum RAM | 64 GB |
| Memory Slot | 2 x DIMM |
Motherboard
| Chipset Manufacturer | Intel |
| Northbridge | Z590 |
| RAID Supported | Yes |
| SATA Supported | Yes |
Expansion
| Number of PCI Express Slots | 1 x PCI Express 4.0 x16 |
Graphics Device
| Integrated Graphics Supported | Yes |
Sound
| Integrated Sound | ROG SupremeFX ALC4080 |
Warranty
| Warranty | 3 Years |
Network
| Integrated Network | Intel I225-V |
| Network Speeds Supported | Up to 2.5 Gbps |
| Wireless LAN | Yes (Wi-Fi 6) |
| Wireless Network Speed | Up to 2.4 Gbps |
| Bluetooth | Yes |
| Bluetooth Version | 5.2 |
System Requirements
| Operating Systems Supported | Microsoft Windows 10 64-bit |
System
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Jumpers | 1 x Clear CMOS |
| Software Included (may be trial or restricted) | Yes |
| Drivers | Yes |
Physical
| Form Factor | Mini-ITX Motherboard |
| In The Box | ROG Strix Z590-I Gaming WiFi Motherboard 4 x SATA Cables Panel Cable ROG USB2.0 Splitter Cable ASUS Wi-Fi Moving Antennas Cable Ties Pack 2 x M.2 Screw Packages 1 x ROG Key Chain 1 x ROG Strix Stickers 1 x ROG Thank You Card Support DVD User Manual |
| Width | 170 mm |
| Length | 170 mm |
Key Features
| RGB Header Type | 3-Pin ARGB |
| Addressable RGB | Yes |
| Firewire | No |
| Wireless Network | Yes |
| Memory Channel | Dual |
| On-board Audio Type | 7.1 |
| Number of SATA Ports | 4 port(s) |
| Number of USB Ports | 7 port(s) |
| SATA III Support | Yes |
| USB 3.0 Support | Yes |
| Multi GPU Support | No |
| VGA Connection | No |
| DVI Connection | No |
| HDMI Connection | Yes |
| DisplayPort Connection | No |
| Motherboard Form Factor | ITX |
| Motherboard Power Connectors | 4 + 4-Pin |
| Motherboard Chipset | Intel Z590 |
| Thunderbolt | Yes |
| Motherboard Model | ASUS ROG Strix Z590-I Gaming WiFi |
| WiFi Speed | 2400 Mbps |
| USB 3.1 Support | Yes |
| Internal USB3.0 Header | Yes |
| M.2 Support | Yes |
| On-board RGB Control | ASUS Aura Sync |
| Memory Speed | 5133 MHz |
Item Details
| Manufacturer | ASUS |
| Manufacturer Code | 90MB1680-M0EAY0 |
| Alternative Part Numbers | ROG STRIX Z590-I GAMING WIFI, STRIX Z590-I GAMING WIFI |
| EAN | 4711081097952 |
| Condition | New |
