The ZOTAC GAMING GeForce RTX™ 5090 AMP Extreme INFINITY offers a completely revamped gaming experience with a whole new approach to Graphics Card design, featuring NVIDIA's cutting-edge Blackwell architecture and features such as DLSS 4. With an elegant design punctuated by a gorgeous infinity mirror in the front, a reinforced mid-frame, and a vapor chamber larger than its predecessor, the AMP Extreme INFINITY gives you infinite possibilities for gaming, or applications beyond.
Zotac GeForce RTX 5090 AMP Extreme INFINITY OC 32GB GDDR7 Graphics Card
GPU
| Chipset Manufacturer | NVIDIA |
| Chipset Model Name | GeForce RTX |
| Chipset Model Number | 5090 |
| Chipset Additional Information | AMP Extreme INFINITY |
| Base Chip Clock | 2017 MHz |
| Boost Chip Clock | 2467 MHz |
| Graphics Core | CUDA |
| Number of Cores | 21760 |
Memory
| Memory Size | 32768 MB |
| Memory Clock | 28 Gbps |
| Memory Type | GDDR7 |
| Memory Width | 512 bit |
| Memory Bandwidth | 1.79 TB/s |
Interfaces/Ports
| Video Card Bus Type | PCI Express |
| Video Card Bus Version | 5.0 x16 |
| HDMI Port | 1 x HDMI 2.1b |
| DisplayPort | 3 x DisplayPort 2.1a |
Resolution
| Multiple Monitor Support (Max) | Yes (4) |
| Maximum Resolution | 7680 x 4320 |
System Requirements
| System Requirements | 1 x PCI Express 5.0 x16 slot |
Electrical
| Power Connector | 1 x 12V-2x6 or 4 x 8-pin PCIe |
| Power Consumption | 600 W |
| Recomended Power Supply | 1000 W |
Physical
| Form Factor | Graphics Card |
| In The Box | Graphics Card User Manual 1 x 12V-2x6 to 4 x 8-pin PCIe adapter SPECTRA Link cable GPU support stand |
| Width | 69.6 mm (3.5 slot) |
| Depth | 332.1 mm |
| Height | 137.5 mm |
Warranty
| Warranty | 3 Years |
Key Features
| Interface Type | PCI Express 5.0 x16 |
| Config Gaming x8 (CB/CCL) | No |
| Graphics Memory Type | GDDR7 |
| Main Colour | Black |
| VGA Connection | No |
| DVI Connection | No |
| HDMI Connection | Yes |
| Graphics Usability | Gaming |
| DisplayPort Connection | Yes |
| Direct X Support | Direct X 12 |
| Cooler Type | Dynamic Fan Inc. 0dB Mode |
| Low Profile | No |
| NVIDIA GeForce | RTX 5090 |
| PCIe Pin Type | 12+4-Pin (16-Pin) |
| Cooling Technology | Dynamic Fan Inc. 0dB Mode |
| VR Ready | NVIDIA |
| GPU Length | 333 mm |
| Card Width | 4 |
| Power Requirement (auto) | 600 W |
| GPU Power (TDP) | 600 W |
| Graphics card count | 1 |
| PCI Express Power Pins (female) | 32 |
| PCIe Physical Slot required | 16 |
| 12VHPWR 16-pin Connector | Yes |
| AI Ready | Yes |
| 12V-2x6 Rating | 600W |
Graphics
| Graphics Chipset | GeForce RTX 5090 |
Graphics Device
| G-Sync | Yes |
Item Details
| Manufacturer | Zotac |
| Manufacturer Code | ZT-B50900B-10P |
| EAN | 8886307700018 |
