MSI GeForce RTX 5070 Ti INSPIRE 3X OC 16GB GDDR7 Graphics Card

Part Number: RTX 5070 Ti 16G INSPIRE 3X OC
Manufacturer: MSI
Quickfind Code: 125883

Stock: Out Stock

Contact for availability

Product Features:

Condition: New
GPU RTX 5070 Ti
Capacity 16GB
Connection PCI-E
Memory Type GDDR7
Series RTX
GPU Manufacturer Nvidia

+ Read More Information

BIG VISION, SMALL FORM

INSPIRE seamlessly fuses a sleek, compact design with cutting-edge performance, offering advanced capabilities while ensuring seamless compatibility with creative and professional builds.

INSPIRE reinvents your build with its Mondrian grid design—a pristine blend of modern art and advanced technology that inspires creativity and enhances your productivity.

Compact Design, Boundless Creativity

INSPIRE combines a small form factor with enhanced performance, making it the perfect fit for creative professionals seeking efficiency.

Triple-Fan Thermal Design

Three fans on a large heatsink deliver both superior and quieter cooling.

Main Features

Powered by the NVIDIA Blackwell architecture and DLSS 4
SFF-Ready Enthusiast GeForce Card
STORMFORCE FAN: Seven fan blades, claw texturing, and a circular arc are designed for optimal airflow with minimal noise.
Nickel-plated Copper Baseplate: Heat from the GPU and memory is swiftly captured by a nickel-plated copper baseplate and transferred.
Core Pipes feature a square design to maximize contact with the GPU baseplate for optimal thermal management.
WAVE-CURVED 3.0: Additional efficiency is gained by adjusting the size of the wave edges under the fan motor and other spots where there is less airflow.
AIR ANTEGRADE FIN: Fins with a V-shaped cutout are located at the airflow passthrough to improve flow efficiency. Optimizing the inclination angle and increasing the wave notch shapes the air resistance towards the center, pushing out warm air faster like a nozzle.
Metal Backplate: A reinforcing metal backplate with airflow vents and thermal pads enhances cooling.
MSI Center: The exclusive MSI Center software lets you monitor, tweak and optimize MSI products in real-time.
Afterburner software takes full control with the most recognized and widely used graphics card overclocking software in the world.

Technical Specification

MSI GeForce RTX 5070 Ti INSPIRE 3X OC 16GB GDDR7 Graphics Card

GPU

Chipset Manufacturer	NVIDIA
Chipset Model Name	GeForce RTX
Chipset Model Number	5070 Ti
Chipset Additional Information	INSPIRE 3X OC
Boost Chip Clock	2482 MHz
Graphics Core	CUDA
Number of Cores	8960

Memory

Memory Size	16384 MB
Memory Clock	28 Gbps
Memory Type	GDDR7
Memory Width	256 bit

Interfaces/Ports

Video Card Bus Type	PCI Express
Video Card Bus Version	5.0 x16
HDMI Port	1 x HDMI 2.1b
DisplayPort	3 x DisplayPort 2.1b

Resolution

Multiple Monitor Support (Max)	Yes (4)
Maximum Resolution	7680 x 4320

System Requirements

1 x PCI Express 5.0 x16 slot

Electrical

Power Connector	1 x 12V-2x6
Power Consumption	300 W
Recomended Power Supply	750 W

Physical

Form Factor	Graphics Card
In The Box	Graphics Card
Width	50 mm (2.5 slot)
Depth	288 mm
Height	112 mm
Weight	904 g

Warranty

3 Years

Key Features

Interface Type	PCI Express 5.0 x16
Config Gaming x8 (CB/CCL)	Yes
Graphics Memory Type	GDDR7
Main Colour	Gold
VGA Connection	No
DVI Connection	No
HDMI Connection	Yes
Graphics Usability	Gaming
DisplayPort Connection	Yes
Direct X Support	Direct X 12
Cooler Type	Dynamic Fan Inc. 0dB Mode
Low Profile	No
NVIDIA GeForce	RTX 5070 Ti
PCIe Pin Type	12+4-Pin (16-Pin)
Cooling Technology	Dynamic Fan Inc. 0dB Mode
VR Ready	NVIDIA
GPU Length	288 mm
Card Width	3
Power Requirement (auto)	300 W
GPU Power (TDP)	300 W
Graphics card count	1
PCI Express Power Pins (female)	24
PCIe Physical Slot required	16
12VHPWR 16-pin Connector	Yes
AI Ready	Yes
12V-2x6 Rating	450W
