Features
• Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing
• 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
• 3rd Generation RT Cores: Up to 2X ray tracing performance
• Powered by GeForce RTX™ 4070 Ti
• Integrated with 12GB GDDR6X 192bit memory interface
• WINDFORCE Cooling System
• RGB Fusion
• Dual BIOS
• Protection metal back plate
• Anti-sag bracket
WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features three 100mm unique blade fans, alternate spinning, 7 composite copper heat pipes, a vapor chamber directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.
ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.
UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.
GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.
SCREEN COOLING
Extended heatsink allows air to pass through, providing better heat dissipation.
Gigabyte GeForce RTX?? 4070 Ti 12GB GAMING OC Graphics Card
| Key Specifications | |
|---|---|
| Chipset | GeForce RTX 4070 Ti |
| Edition | GAMING OC |
| Manufacturing process | 4 nm |
| Microarchitecture | Ada Lovelace |
| Cores & Clocks | |
|---|---|
| Cores | 7680 |
| Core Clock | |
| Boost Clock | 2640 MHz |
| Video Memory (VRAM) | |
|---|---|
| Memory Size | 12GB |
| Memory Type | GDDR6X |
| Memory Clock | 21000 MHz |
| Memory Bus | 192 Bit |
| Cooling | |
|---|---|
| Cooling Solution | Tri Fan (3) |
| Included/Fitted Backplate | Yes |
| I/O & Connectivity | |
|---|---|
| Interface | PCIe 4.0 |
| Connectivity |
|
| Visuals | |
|---|---|
| GeForce VR Ready | Yes |
| Multi-Way Graphics Support | |
| Microsoft DirectX Support | 12 API |
| HDCP Ready | Yes |
| Max. Concurrent Displays | 4 Displays |
| Maximum Digital Resolution | 7680x4320 (8K UHD) |
| Ray-Tracing | |
|---|---|
| Real-Time Ray Tracing | Yes |
| NVIDIA RT Cores | |
| NVIDIA Tensor Cores | |
| RTX-OPS | |
| Rays Cast | |
| Power & Thermals | |
|---|---|
| Graphics Card Power Connectors | 1 x 16-pin PCIe |
| Graphics Card TDP/Power | |
| Minimum Recommended PSU | 750 W |
| Maximum GPU Temperature | 90 °C |
| Physical | |
|---|---|
| Width | 2.5 Slot |
| Low Profile Compatible | No |
| Low Profile Support | N/A |
| Dimensions | 336 x 140 x 58 mm |
| Package Type | Retail |
