ASUS Radeon RX 9060 XT Prime OC 8GB GDDR6 Graphics Card

  • Part Number: 90YV0MI0-M0NA00
  • Manufacturer: ASUS
  • Quickfind Code: 126003

  • Stock: Out Stock

Contact for availability


Product Features:
  • Condition: New
  • GPU RX 9060 XT
  • Capacity 8GB
  • Connection PCI-E
  • Memory Type GDDR6
  • Series RX XT
  • GPU Manufacturer AMD
+ Read More Information

Share:

Product Description

Primed for Power

PRIME Radeon™ RX 9060 XT

Experience Primal performance with the Prime Radeon™ RX 9060 XT graphics card featuring a compact 2.5-slot design for expansive compatibility, enhanced by a triple-fan setup for supreme cooling.


  • OC mode (GPU Tweak III): Up to 3330 MHz (Boost Clock)/ up to 2760 MHz (Game Clock)
  • Axial-tech fans feature a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure
  • 2.5-slot design allows for greater build compatibility while maintaining cooling performance
  • Dual-ball fan bearings last up to twice as long as standard sleeve bearings
  • 0dB technology lets you enjoy light gaming in relative silence
  • Dual BIOS switch lets you toggle between Quiet and Performance BIOS profiles
  • Auto-Extreme manufacturing process for precision and reliability
  • GPU Tweak III software provides intuitive performance tweaking, advanced thermal control and system monitoring
Technical Specification

ASUS Radeon RX 9060 XT Prime OC 8GB GDDR6 Graphics Card

GPU

Chipset ManufacturerAMD
Chipset Model NameRadeon RX
Chipset Model Number9060 XT
Chipset Additional InformationPrime
Boost Chip ClockUp to 3330 MHz
Number of Cores2048

Memory

Memory Size8192 MB
Memory Clock20 Gbps
Memory TypeGDDR6
Memory Width128 bit

Interfaces/Ports

Video Card Bus TypePCI Express
Video Card Bus Version5.0 x16
HDMI Port1 x HDMI 2.1b
DisplayPort2 x DisplayPort 2.1a

Resolution

Multiple Monitor Support (Max)Yes (3)
Maximum Resolution7680 x 4320

System Requirements

System Requirements1 x PCI Express 5.0 x16 slot

Electrical

Power Connector1 x 8-pin PCIe
Recomended Power Supply550 W

Physical

Form FactorGraphics Card
In The BoxGraphics Card
Thank You Card
Speedsetup Manual
Width50 mm (2.5 slot)
Depth304 mm
Height126 mm
Weight0.871 kg

Warranty

Warranty3 Years

Key Features

Interface TypePCI Express 5.0 x16
Config Gaming x8 (CB/CCL)Yes
Graphics Memory TypeGDDR6
Main ColourBlack
VGA ConnectionNo
DVI ConnectionNo
HDMI ConnectionYes
Graphics UsabilityGaming
DisplayPort ConnectionYes
Direct X SupportDirect X 12
Cooler TypeDynamic Fan Inc. 0dB Mode
Low ProfileNo
AMD RadeonRX 9060 XT
PCIe Pin Type6+2-Pin
FreeSyncYes
Cooling TechnologyDynamic Fan Inc. 0dB Mode
VR ReadyAMD
GPU Length304 mm
Card Width3
Power Requirement (auto)150 W
GPU Power (TDP)150 W
Graphics card count1
PCI Express Power Pins (female)8
PCIe Physical Slot required16
12VHPWR 16-pin ConnectorNo

Graphics

Graphics ChipsetRadeon RX 9060 XT

Item Details

ManufacturerASUS
Manufacturer Code90YV0MI0-M0NA00
EAN4711387994184
UPC197105994188
