Deep in ASUS R&D labs, engineers theorised the optimal thermal solution for AMD's latest RDNA™ 2 Architecture. The beast that emerged is a liquid-cooled leviathan capable of drawing maximum performance out of the new chips, while remaining completely cool and quiet. Performance aficionados in search of the most ferocious RX 6900 XT card have found their game.
Full-Coverage Cold Plate
A custom-designed cold plate extends over the GPU die and the onboard GDDR6 memory, bringing the full benefits of liquid-cooling to the components most responsible for raw performance.
On-Board Cooling
In the belly of the beast, heat produced by power-delivery components is dispelled by a blower-style fan and a low-profile heatsink under the shroud. The combo exhausts hot air quietly and efficiently.
Radiator Fans
The 240mm radiator is cooled by two powerful 120mm ARGB fans that are optimised for high CFMs and static pressure.
The LC utilises 600mm tubing to enable compatibility with large chassis or builds that feature an AIO CPU cooler. The radiator fan cables can be connected directly to the card and secured with included cable ties to keep everything organised.
Top-shelf capacitors, chokes, and MOSFETs are selected to effortlessly deliver hundreds of watts at a millisecond's notice. The Super Alloy Power II parts are soldered to the PCB using our advanced Auto-Extreme automated manufacturing process. Precise joints and the elimination of human error ensures each graphics card meets our rigorous specifications.
The rear of the card sports two PWM FanConnect headers that provide additional DIY flexibility. Chassis fans can be directly attached to the GPU and tuned with a curve that is based on CPU and GPU temperatures, providing extra intake or exhaust for demanding 3D tasks.
You won't find the Strix LC hiding in the shadows. Instead, this denizen of the deep flaunts its power with addressable RGB lighting that shines through striations in the shroud, an illuminated ROG logo, and two ARGB radiator fans.
The ASUS GPU Tweak II utility takes graphics card tuning to the next level. It allows you to tweak critical parameters including GPU core clocks, memory frequency, and voltage settings, with the option to monitor everything in real-time through a customisable on-screen display. Advanced fan control is also included along with many more features to help you get the most out of your graphics card.
The latest Radeon™ Software Adrenalin 2020 Edition unleashes the full potential of your GPU with day-0 drivers optimised for new game releases and a highly customisable gaming experience.
ASUS Radeon RX 6900 XT ROG Strix LC 16GB OC GPU
GPU
| Chipset Manufacturer | AMD |
| Chipset Model Name | Radeon RX |
| Chipset Model Number | 6900 XT |
| Chipset Additional Information | ROG Strix LC OC |
| Chip Clock | Up to 2365 MHz |
Storage
| Memory Size | 16384 MB |
Memory
| Memory Clock | 16 Gbps |
| Memory Type | GDDR6 |
| Memory Width | 256 bit |
Interfaces/Ports
| Video Card Bus Type | PCI Express |
| Video Card Bus Version | 4.0 x16 |
| HDMI Port | 1 x HDMI 2.1 |
| DisplayPort | 2 x DisplayPort 1.4a 1 x USB Type-C |
System Requirements
| System Requirements | 1 x PCI Express 4.0 x16 slot Recommended 850W PSU with 3 x 8-pin PCIe connectors 2 x 120mm fan mounts to support a 240mm radiator system |
Resolution
| Multiple Monitor Support (Max) | Yes (4) |
| Maximum Resolution | 7680 x 4320 pixels |
Physical
| Form Factor | Graphics Card |
| In The Box | Graphics Card ROG Velcro Hook & Loop ASUS Ruler Collection Card Speedsetup Manual Cable Ties Pack |
| Width | 43.6 mm (2.2 slot) |
| Depth | 277 mm |
| Height | 131 mm |
| Weight | 2.198 kg |
Warranty
| Warranty | 3 Years |
Key Features
| Interface Type | PCI Express 4.0 x16 |
| VGA Connection | No |
| DVI Connection | No |
| HDMI Connection | Yes |
| Graphics Usability | Gaming |
| DisplayPort Connection | Yes |
| Direct X Support | Direct X 12 |
| Cooler Type | Closed Loop Watercooler |
| Low Profile | No |
| AMD Radeon | RX 6900 XT |
| PCI-E Pin Type | 8-Pin x 3 |
| FreeSync | Yes |
| Cooling Technology | Dynamic Fan |
| VR Ready | AMD |
| GPU Length | 277 mm |
| Card Width | Triple Slot |
Graphics
| Graphics Chipset | Radeon RX 6900 XT |
Item Details
| Manufacturer | ASUS |
| Manufacturer Code | 90YV0GF0-M0NM00 |
| Alternative Part Number | ROG-STRIX-LC-RX6900XT-O16G-GAMING |
| EAN | 4711081071785 |
| Condition | New |
