The TUF Gaming Radeon™ RX 6500 XT is a tenacious beast with a tough metal exterior, efficient cooling, and components that offer enhanced endurance. An all-metal shroud houses two powerful axial-tech fans with dual ball fan bearings. Underneath, a thick heatsink keeps thermals under tight control and TUF components, selected for maximum durability and performance, keep the card ahead of the pack. You asked for a mean machine... this one is ready for action.
Two tried-and-true Axial-tech fans feature a smaller hub that facilitates longer blades and a slimmed down barrier ring to provide better airflow through the cooling array.?
Fans will only start spinning when the GPU temperature hits 57 Celsius and shut off when temps drop below 50 Celsius, helping to reduce noise when the system is idling or under light load.
The heat spreader draws heat up into heatpipes that carry it through a fin stack that fills most of the card’s large, 2.7-slot footprint.
Robust military-grade capacitors were selected for the card’s power design. They and other components are soldered to the PCB using our Auto-Extreme automated manufacturing process. Precise joints and the elimination of human error ensures each graphics card meets our rigorous specifications. To ensure flawless performance when it counts, the cards are subjected to a grueling 144-hour validation trial.
A machined all-aluminum shroud creates a robust outer shell and a no-nonsense industrial design and grayscale colorway fits into any build with ease.
The underside of the card reveals further improvements. Most of the rear is swathed in a protective metal backplate that prominently features a wide vent. The vent allows hot air to escape towards chassis exhaust fans instead of being recycled back into the GPU cooler. Stainless steel is used for the I/O bracket to protect ports and provide a more secure mount. And a conveniently placed Dual Bios switch allows customization of the card’s default performance profile without software.
The front-side RGB element can be customized to display a range of aesthetic and functional effects, and also synced with other ASUS components to enable uniform lighting. To fulfill the power demands of the Radeon RX 6500 XT, a 6-pin power connector is present, along with onboard LEDs that light up if PSU PCIe power connectors are not plugged in correctly.
ASUS Radeon RX 6500 XT TUF 4GB OC GPU
GPU
| Chipset Manufacturer | AMD |
| Chipset Model Name | Radeon RX |
| Chipset Model Number | 6500 XT |
| Chipset Additional Information | TUF Gaming OC |
Storage
| Memory Size | 4096 MB |
Memory
| Memory Clock | 18 Gbps |
| Memory Type | GDDR6 |
| Memory Width | 64 bit |
Interfaces/Ports
| Video Card Bus Type | PCI Express |
| Video Card Bus Version | 4.0 x4 |
| HDMI Port | 1 x HDMI 2.1 |
| DisplayPort | 1 x DisplayPort 1.4 |
System Requirements
| System Requirements | 1 x PCI Express 4.0 x16 slot Recommended 500W or greater PSU with 1 x 6-pin PCIe connector |
Resolution
| Multiple Monitor Support (Max) | Yes (2) |
| Maximum Resolution | 7680 x 4320 pixels |
Physical
| Form Factor | Graphics Card |
| In The Box | Graphics Card Speedsetup Manual Collection Card |
| Width | 54 mm (Triple Slot) |
| Depth | 250 mm |
| Height | 147 mm |
| Weight | 0.881 kg |
Warranty
| Warranty | 3 Years |
Key Features
| Interface Type | PCI Express 4.0 |
| VGA Connection | No |
| DVI Connection | No |
| HDMI Connection | Yes |
| Graphics Usability | Gaming |
| DisplayPort Connection | Yes |
| Direct X Support | Direct X 12 |
| Cooler Type | Dynamic Fan |
| Low Profile | No |
| AMD Radeon | RX 6500 XT |
| PCI-E Pin Type | 6-Pin |
| FreeSync | Yes |
| Cooling Technology | Dynamic Fan |
| GPU Length | 250 mm |
| Card Width | Triple Slot |
Graphics
| Graphics Chipset | Radeon RX 6500 XT |
Item Details
| Manufacturer | ASUS |
| Manufacturer Code | 90YV0HA0-M0NA00 |
| EAN | 4711081591832 |
| UPC | 195553591836 |
| Condition | New |
