ASUS GeForce RTX 5060 Ti TUF OC 8GB GDDR7 Graphics Card

  • Part Number: 90YV0MR0-M0NA00
  • Manufacturer: ASUS
  • Quickfind Code: 125828
  • Stock: In Stock

£456.66 ex. vat
£547.99 inc. vat

Product Features:
  • Condition: New
  • GPU RTX 5060 Ti
  • Capacity 8GB
  • Connection PCI-E
  • Memory Type GDDR7
  • Series RTX
  • GPU Manufacturer Nvidia
+ Read More Information

Share:

Product Description

NVIDIA Blackwell architecture is elevated by enhanced cooling and power delivery, fortified with rugged reinforcements for exceptional durability. Lock, load and dominate with the TUF Gaming GeForce RTX™ 5060 Ti, designed to withstand the harshest conditions and deliver unparalleled performance.

Main Features

  • AI Performance: 785 AI TOPS
  • OC mode boosts clock 2692 MHz (OC mode)/ 2662 MHz (Default mode)
  • Powered by the NVIDIA Blackwell architecture and DLSS 4
  • Military-grade components deliver rock-solid power and longer lifespan for ultimate durability
  • Protective PCB coating helps protect against short circuits caused by moisture, dust or debris
  • 3.1-slot design with massive fin array optimized for airflow from three Axial-tech fans
  • ASUS GPU Guard secure the GPU, reducing the risk of cracks
  • Auto-Extreme precision automated manufacturing helps ensure higher reliability
  • GPU Tweak III software provides intuitive performance tweaking, advanced thermal controls and system monitoring
Technical Specification

ASUS GeForce RTX 5060 Ti TUF OC 8GB GDDR7 Graphics Card

GPU

Chipset ManufacturerNVIDIA
Chipset Model NameGeForce RTX
Chipset Model Number5060 Ti
Chipset Additional InformationTUF Gaming OC
Boost Chip Clock2662 MHz
Graphics CoreCUDA
Number of Cores4608

Memory

Memory Size8192 MB
Memory Clock28 Gbps
Memory TypeGDDR7
Memory Width128 bit
Memory Bandwidth448 GB/s

Interfaces/Ports

Video Card Bus TypePCI Express
Video Card Bus Version5.0 x8
HDMI Port1 x HDMI 2.1b
DisplayPort3 x DisplayPort 2.1b

Resolution

Multiple Monitor Support (Max)Yes (4)
Maximum Resolution7680 x 4320

System Requirements

System Requirements1 x PCI Express 5.0 x16 slot

Electrical

Power Connector1 x 12V-2x6 or 2 x 8-pin PCIe
Power Consumption180 W
Recomended Power Supply550 W

Physical

Form FactorGraphics Card
In The BoxGraphics Card
Speedsetup Manual
TUF Graphics Card Holder
TUF Velcro Hook & Loop
TUF Gaming Certificate
Thank You Card
Adapter Cable (1 to 2)
Width62 mm (3.1 slot)
Depth302 mm
Height133.5 mm

Warranty

Warranty3 Years

Key Features

Interface TypePCI Express 5.0 x8
Graphics Memory TypeGDDR7
Main ColourBlack
VGA ConnectionNo
DVI ConnectionNo
HDMI ConnectionYes
Graphics UsabilityGaming
DisplayPort ConnectionYes
Direct X SupportDirect X 12
Cooler TypeDynamic Fan Inc. 0dB Mode
Low ProfileNo
NVIDIA GeForceRTX 5060 Ti
PCIe Pin Type12+4-Pin (16-Pin)
Cooling TechnologyDynamic Fan Inc. 0dB Mode
VR ReadyNVIDIA
GPU Length302 mm
Card Width3
Power Requirement (auto)180 W
GPU Power (TDP)180 W
Graphics card count1
PCIe Physical Slot required16
12VHPWR 16-pin ConnectorYes
AI ReadyYes
12V-2x6 Rating300W

Graphics

Graphics ChipsetGeForce RTX 5060 Ti

Graphics Device

G-SyncYes

Item Details

ManufacturerASUS
Manufacturer Code90YV0MR0-M0NA00
EAN4711387994375
