Phanteks M25 Gen2 140mm DRGB Reverse Airflow PWM Triple Fan Pack Black
- Part Number: PH-F140M25R_G2_DBK01_3P
- Manufacturer: Phanteks
- Quickfind Code: 120882
- Stock: In Stock
£24.85 ex. vat
£29.82 inc. vat
Share:
For sales and support
Call:0161 480 8800
Product Description
Single Cable Solution
- The Linq6 connector consolidates both fan and lighting controls into one cable for a cleaner, more efficient build.
- Integrated D-RGB Lighting, features smooth, dynamic lighting with an infinity mirror effect for striking visuals.
Daisy-Chain Unified Fan Design
- Easily connect multiple fans with a streamlined setup, minimizing clutter.
- Connect fans easily by sliding and locking with a screw.
- Sleek Aesthetic, included screw covers provide a polished and professional look.
Versatile Airflow Options
- Reverse airflow model for optimal system configuration.
- High Cooling Performance, designed to excel on radiators and heat sinks for efficient thermal management.
Integrated Lighting
- The LINQ6 connector simplifies cable management by combining power for both the fan and D-RGB lighting into a single, easy-to-use connection.
- The hub showcases an infinity mirror design, adding a striking visual illusion of endless depth for an eye-catching aesthetic.
* To operate the D-RGB lighting, it must be connected to a Phanteks controller or an A-RGB equipped mainboard. We strive to make it as easy to use and compatible as possible.
Technical Specification
Phanteks M25 Gen2 140mm DRGB Reverse Airflow PWM Triple Fan Pack Black
Attributes
| Fan Speed | 350 ~ 1800 RPM |
| Air Flow | 100.07 CFM Max |
| Bearing Type | Hydraulic |
| Connector | Linq6 |
| Fan Air Pressure | 2.04 mmH2O Max |
Electrical
| Voltage | 12 V |
| Current | 0.3 A |
Environmental
| Noise Level | 40.95 dBA Max |
Physical
| Form Factor | Chassis Fans |
| Case Colour | Black |
| Cable length | 140 mm |
| In The Box | 3 x Fans 2 x Linq6 Extension Cables 1 x Linq6 Adapter Cable 8 x Screw Cover Corners 4 x Screw Cover Bridges 14 x Fan Screws |
| Fan Width | 140 mm |
| Fan Depth | 140 mm |
| Fan Height | 25 mm |
| Fan Weight | 563 g total |
Warranty
| Warranty | 3 Years |
Key Features
| Main Colour | Black |
| Fan Size | 140 mm |
| L.E.D Fan | ARGB |
| Number of Fans | 3 fan(s) |
| RGB LED Controller Included | No |
| LED Strip(s) Included | No |
| Fan Connector | Proprietary |
| Power Requirement (auto) | 9 W |
| Fan Blade Direction | Reverse |
Item Details
| Manufacturer | Phanteks |
| Manufacturer Code | PH-F140M25R_G2_DBK01_3P |
| EAN | 0886523003649 |
