Lian Li UNI FAN CL Wireless Reverse Fan 120mm White
- Part Number: 12RCL1W1W
- Manufacturer: Lian Li
- Quickfind Code: 120900
- Stock: In Stock
£17.89 ex. vat
£21.47 inc. vat
Share:
For sales and support
Call:0161 480 8800
Product Description
The UNI FAN CL Wireless Reverse Flow 120 mm brings cable-free convenience and advanced cooling to your build with a unique reverse blade design. Engineered to direct airflow in the opposite direction of standard fans, it’s ideal for radiator pull configurations or exhaust placement where reversed airflow is needed.
Like the standard version, it uses Lian Li’s wireless control system to eliminate cable clutter, while the interlocking design makes connecting multiple fans simple and secure. Dual-zone ARGB lighting on the blades and side strips offers vibrant, customisable effects through L-Connect 3 software, ensuring your build stands out.
Built with fluid dynamic bearings for quieter performance and long-term reliability, the UNI FAN CL Wireless Reverse Flow balances airflow, static pressure, and aesthetics in a flexible cooling solution tailored for modern PC builds.
Main Features
- Reverse Blade Design - Directs airflow opposite to standard fans, ideal for exhaust or radiator pull setups.
- Wireless Control - Fan speed and ARGB lighting managed via 2.4 GHz controller and L-Connect 3 software.
- UNI FAN Interlocking System - Snap fans together for a clean, cable-free installation.
- Dual-Zone ARGB Lighting - Independent lighting on fan blades and side strips for vivid effects.
- 28 mm Thick Frame - Provides strong airflow and static pressure for demanding cooling tasks.
- Fluid Dynamic Bearing - Quieter operation with improved durability.
- High Airflow Performance - Up to 72.73 CFM with 2.52 mmH2O static pressure.
- Low Noise Output - Max acoustic noise around 30.8 dBA.
- Premium Build - Durable PBT, PC, and aluminum materials.
- 3-Year Warranty - Backed by Lian Li for long-term reliability.
Technical Specification
Lian Li UNI FAN CL Wireless Reverse Fan 120mm White
Attributes
| Fan Diameter | 120 mm |
| Fan Speed | Up to 2100 RPM |
| Number of Speeds | PWM controlled (variable) |
| Bearing Type | Fluid Dynamic Bearing (FDB) |
| Air Flow | Up to 72.73 CFM |
| CPU Supported | N/A (case/radiator fan, not a CPU cooler) |
| Fan Air Pressure | 2.52 mmH2O |
| Static Pressure | 2.52 mmH2O |
| Socket | N/A |
| Tilt Adjustable | No |
| Lifetime | 3-year warranty (hours not specified) |
| Heat Sink Type | N/A |
| Compatible with: | PC cases, radiators (120 mm fan mounts) |
| PCMCIA Slots | N/A |
Environmental
| Minimum Storage Temperature | 0 øC |
| Maximum Storage Temperature | 40 øC |
| Minimum Storage Humidity | 10% RH |
| Maximum Storage Humidity | 85% RH (typical safe range) |
| Operating Temperature | 0 - 40 øC |
| Operating Humidity | 10 - 85% RH (non-condensing) |
| Noise Level | 30.8 dBA (max) |
Interfaces
| Connector | 4-pin PWM + 2-pin LED tail + integrated wireless receiver |
Electrical
| Voltage | 12 V (fan) & 5 V (LED) |
| Current | 180 mA (fan) / 600 mA (LED) |
Compliance
| Standards | PWM control, 5 V ARGB (addressable) |
| Certifications | CE, FCC, RoHS |
| Safety | Standard PC component electrical safety compliance |
| EMI | CE/FCC compliance |
| Immunity | CE/FCC compliance |
Physical
| Form Factor | 120 mm fan (28 mm thick) |
| Internal/External | Internal (PC case/radiator use) |
| Case Colour | White |
| Cable length | Minimal (short tail for optional wired use |
| Heatsink Material | N/A (this is a fan, no heatsink) |
| In The Box | 1 x UNI FAN CL Wireless Reverse Flow 120 mm White, accessory pack (screws), manual |
| Pack Quantity | 1 |
| Width | 120 mm |
| Depth | 28 mm |
| Height | 120 mm |
| Weight | ~160 g (per fan) |
| Fan Width | 120 mm |
| Fan Depth | 28 mm |
| Fan Height | 120 mm |
| Fan Weight | ~160 g |
| Heatsink Width | N/A |
| Heatsink Height | N/A |
| Heatsink Depth | N/A |
| Form Factor | 120 mm case/radiator fan (28 mm thickness) |
Shipping
| SP Width | ~125 mm (approx. retail single-pack width) |
| SP Depth | ~30-35 mm (approx. retail single-pack depth) |
| SP Height | ~125 mm (single pack retail box height) |
| SP Weight | ~250 g (fan + accessories + box) |
| Shipping Carton Quantity | Varies by distributor (typically 20 single packs per carton) |
| Shipping Carton Product Quantity | 20 |
| SC Width | ~270 mm (outer carton) |
| SC Depth | ~270 mm (outer carton) |
| SC Height | ~270 mm (outer carton) |
| SC Weight | ~5-6 kg (carton with 20 single packs) |
| Trade Carton | Yes |
| Trade Carton Product Quantity | 20 |
| TC Width | ~270 mm |
| TC Depth | ~270 mm |
| TC Height | ~270 mm |
| TC Weight | ~5-6 kg |
| Shipping Pallet Quantity | Varies by distributor (commonly 480-600 single packs per pallet) |
Warranty
| Warranty | 3 years |
Key Features
| Main Colour | White |
| Fan Size | 120 mm |
| L.E.D Fan | ARGB |
| Number of Fans | 1 fan(s) |
| RGB LED Controller Included | No |
| LED Strip(s) Included | No |
| Fan Connector | 4-pin PWM |
| Power Requirement (auto) | 3 W |
| Fan Blade Direction | Reverse |
Item Details
| Manufacturer | Lian Li |
| Manufacturer Code | 12RCL1W1W |
| EAN | 4718466018588 |
