Fractal Design Dynamic X2 GP-14 PWM White Case Fan
- Part Number: FD-FAN-DYN-X2-GP14-PWM-WT
- Manufacturer: Fractal Design
- Quickfind Code: 120497
- Stock: In Stock
£12.14 ex. vat
£14.57 inc. vat
Share:
For sales and support
Call:0161 480 8800
Product Description
Fractal Design Dynamic X2 GP-14 PWM White
Aerodynamic Technology
The Fractal Design Dynamic X2 series are true all-purpose fans, offering excellent airflow and outstanding 100,000-hour life expectancy thanks to the new LLS (Long Life Sleeve) bearing.
Added PWM support offers precise fan control via a wide speed adjustment range allowing users to select their ideal mix of silent operation and maximum airflow.
The customized design of the Dynamic X2 results in a beautiful fan that helps to keep your system cool, yet quiet. Designed together with Fractal Design's high-end Venturi Series, the Dynamic X2 incorporates aerodynamic elements of airplane wing designs for significant noise reduction.
Available in multiple colours including black, white, and the classic Fractal Design white-on-black combination, the Dynamic X2 series are the perfect choice for those seeking an expertly balanced fan with exceptional dependability.
Features
• High-grade LLS bearing with 100,000-hour MTBF delivers long-lasting dependability.
• PWM support offers a wide 500 to 2,000 RPM speed adjustment range for silent operation under lighter loads and maximum airflow during more demanding activity.
• Counter-balanced magnet reduces axial tension on the bearing, resulting in less wear over time.
• Optimized fan geometry balances airflow with extra emphasis on static pressure for great performance in any usage scenario.
• Aerodynamic stator with embedded wiring helps reduce noise and unwanted turbulence.
• Stator struts sit on a wide angle to the trailing edge of the blades, resulting in a lower noise level and smoother noise profile.
• Strategically placed notches near the fan hub on the trailing edge of the blades help to eliminate the humming noise produced when the blades pass stator struts.
• "Trip wire" technology introduces a micro-turbulent layer that helps to combat elements that negatively affect performance, providing an overall more efficient and quieter fan environment.
• Customized design contributes to a cool running and beautiful looking build.
• Available in 120mm and 140mm sizes and multiple colours including black, white or the signature Fractal Design white-on-black combination.
Technical Specification
Fractal Design Dynamic X2 GP-14 PWM White Case Fan
Fractal Design Dynamic X2 GP-14 PWM White
General | |
|---|---|
| Package Content | 4 screws |
| Product Type | Case fan |
| Width | 14 cm |
| Depth | 14 cm |
| Height | 2.5 cm |
| Weight | 185 g |
| Shipping Dimensions (WxDxH) / Weight | 14.2 cm x 2.6 cm x 16.7 cm / 230 g |
| Colour | Black frame, white blades |
Security Cable Lock | |
| Fan Diameter | 140 mm |
| Fan Height | 25 mm |
| Fan Bearing | Long life sleeve bearing |
| Rotation Speed | 1700 rpm |
| Air Flow | 105 cfm |
| Air Pressure | 1.92 mm |
| Noise Level | 33.7 dBA |
| Power Connector | 4-pin fan connector |
| Rated Voltage | 12 V |
| Start Voltage | 6 V |
| Rated Current | 0.25 A |
| Cable Length | 50 cm |
| Features | Pulse-width modulation (PWM) support, trip wire technology, counter-balancing magnet, aerodynamical blade design, 7 fan blade design |
Heatsink & Fan | |
| Fan Diameter | 140 mm |
| Fan Height | 25 mm |
| Fan Bearing | Long life sleeve bearing |
| Rotation Speed | 1700 rpm |
| Air Flow | 105 cfm |
| Air Pressure | 1.92 mm |
| Noise Level | 33.7 dBA |
| Power Connector | 4-pin fan connector |
| Rated Voltage | 12 V |
| Start Voltage | 6 V |
| Rated Current | 0.25 A |
| Cable Length | 50 cm |
| Features | Pulse-width modulation (PWM) support, trip wire technology, counter-balancing magnet, aerodynamical blade design, 7 fan blade design |
Miscellaneous | |
| MTBF | 100,000 hour(s) |
