Phanteks NV9 Full Tower Gaming Case White

  • Part Number: PH-NV923TG_DMW01
  • Manufacturer: Phanteks
  • Quickfind Code: 105967

  • Stock: In Stock

£191.48 ex. vat
£229.78 inc. vat


Product Features:
  • Condition: New
  • Form Factor E-ATX
  • Main Colour White
  • Side Panel Tempered Glass
+ Read More Information

Share:

Product Description

A SHOWCASE OF PERFORMANCE

  • Near-seamless glass panels
  • The mainboard as a centerpiece of your build
  • Build to last from thick reinforced steel

PERFORMANCE WITHOUT COMPROMISE

  • Up to eleven 140mm fan mounts all around the system with a strong outer frame
  • Extensive cooling support for triple 420 radiators plus a 280 radiator simultaneously for high end cooling performance
  • Direct and dedicated GPU cooling from the bottom
  • Immense bottom airflow intake with 65mm clearance
  • Ultra-Fine Performance mesh on all external panels

CLEAN EXTERIOR FROM ALL SIDES

  • The clean rear door and moveable front IO module allows for multiple placement options
  • Rear door swings open to provide easy access
  • Unique cable management system for external cables
  • Go for a zero-cable setup using the hidden cable exit grommet
  • Cover doors and velcro cable combs easily hide and manage the internal cables

UNIQUE INTERIOR FEATURES

  • Versatile GPU support bracket prevents sag and securely holds the GPU to the mainboard
  • Removeable side and bottom fan bracket for easy installation
  • Bottom bracket can be reversed for angled or horizontal position
  • Included airflow covers to prevent uneven air circulation

NEW GENERATION D-RGB CONTROLLER

  • Integrated D-RGB lighting around the mainboard
  • Dual channel output to allow for dual colour effects
  • A total of 4 output ports and dual SATA power expands the possibilities
  • Refined D-RGB lighting effects that just work, no software required
  • Optionally, choose for software-control with the included cable
Technical Specification

Phanteks NV9 Full Tower Gaming Case White

Storage

Internal Expansion BaysUp to 6 x 2.5"
Up to 3 x 3.5"

Expansion

Expansion Slots8 x Full Height

Interfaces/Ports

USB Ports1 x USB-C 3.1
2 x USB 3.0
Headphone Ports1 x 3.5mm COMBO Jack
Microphone In PortShared with Headphone

Electrical

Cooling SystemTop: Supports 3 x 140mm or 120mm fans
Rear: Supports 2 x 140mm or 120mm fans
Bottom: Supports 3 x 140mm or 120mm fans
Side: Supports 3 x 140mm or 4 x 120mm fans
Power SupplyATX Power Supply supported

Physical

Form FactorFull Tower Case
Case ColourMatte White
MaterialSteel
Tempered Glass
Kensington Lock Slot280 mm
Motherboard CompatibilitySSI-CEB
E-ATX (up to 280mm)
ATX
mATX
Mini-ITX
In The BoxCase
Accessory Box
Width575 mm
Depth615 mm
Weight19.52 kg

Warranty

Warranty5 Years

Key Features

Max Motherboard Width280 mm
Max Motherboard Height305 mm
Supports AIO CoolerYes
Main ColourWhite
Case TypeTower
Case Form FactorFull Tower
Power Supply IncludedNo
Optimised forGaming
80Plus RatedNo
PSU Form FactorATX
IlluminatedYes
L.E.D FanNo LED
Max 3.5" Drives3
Max 2.5" Drives6
ATXYes
Micro-ATXYes
ITXYes
E-ATXYes
Cooler Height205 mm
Built-in Card ReaderNo
USB Type-C SupportYes
Side Panel TypeTempered Glass
GPU Length490 mm
PSU Depth205 mm
RGB LED Controller IncludedYes
LED Strip(s) IncludedNo
Maximum Motherboard Size SupportedE-ATX
RGB Software TypeNone
Total 2.5" + 3.5" drive bays6
USB3.0 ports2
USB-C ports1
Low profile expansionNo
Max Supported Radiator Length420 mm
Create Your Own Gaming PC (CCL)No
Back Connect SupportNo

Item Details

ManufacturerPhanteks
Manufacturer CodePH-NV923TG_DMW01
EAN0886523303084
