Phanteks Eclipse G400A Mid Tower Gaming Case Black

Part Number: PH-EC400GA_DBK01
Manufacturer: Phanteks
Quickfind Code: 105969

Stock: In Stock

£74.89 ex. vat
£89.87 inc. vat

Product Features:

Condition: New
Form Factor E-ATX
RGB / LED Colour RGB
Main Colour Black
Side Panel Tempered Glass

+ Read More Information

Product Description

The G400A is the upgraded successor to the popular P400A, featuring a completely redesigned and more spacious chassis. It’s perfect for clean, modern hardware setups, easily accommodating even the largest graphics cards while leaving ample room for cable management. With up to 10 fan mounting points, support for 140 mm fans, and dedicated radiator space at the top, cooling performance has been significantly enhanced.

The G400A also supports the latest mainboards, with rear side connectors hidden to enable a cable-free appearance. Additionally, the graphics card benefits from direct cooling via three 120mm fan mounts on the mid-plate.

Clean front inlet design

Clean design allows for focused airflow.
4x M25-140 Gen2 D-RGB fans included.
Dedicated 360 radiator support in the top without restrictions.

Improved Air Intake

45% open surface for more air intake compared to standard mesh which only provides 35%.

Ultra-fine Performance Mesh

Large mesh intake areas on both side panels for high cooling performance.
Triple mid-plate 120 fan locations for direct GPU cooling.
Support for the largest graphics cards without compromise.

Clean Cable Management

Dedicated cable management tool.
Support for the latest rear-side connector mainboards.

New Generation D-RGB

4x M25-140 Gen2 D-RGB fans pre-installed.
Build-in horizontal D-RGB strip.

NextLinq

Expand with more D-RGB by using our Nexlinq ecosystem, which makes both lighting and fan control a breeze with its lightweight software.

Technical Specification

Phanteks Eclipse G400A Mid Tower Gaming Case Black

User Controls

Power
Reset

Storage

Internal Expansion Bays

2 x 2.5" and 1 x 3.5" OR 2 x 3.5"

Expansion

Expansion Slots

7 x Full Height

Interfaces/Ports

USB Ports	1 x USB-C 3.1 1 x USB 3.0
Headphone Ports	1 x 3.5mm COMBO Jack
Microphone In Port	Shared with Headphone

Electrical

Cooling System	Front: Supports 3 x 140mm fans (3 x ARGB fans included) Top: Supports 2 x 140mm or 3 x 120mm fans Rear: Supports 1 x 140mm or 120mm fan (140mm ARGB fan included) Bottom: Supports 3 x 120mm fans
Power Supply	ATX Power Supply supported

Physical

Form Factor	Mid Tower
Case Colour	Black
Material	Steel Tempered Glass
Motherboard Compatibility	E-ATX (up to 280mm wide) ATX mATX Mini-ITX
In The Box	Case Accessories
Width	230 mm
Depth	495 mm
Height	522 mm
Weight	8.63 kg

Warranty

5 Years

Key Features

Max Motherboard Width	280 mm
Max Motherboard Height	305 mm
Supports AIO Cooler	Yes
Main Colour	Black
Case Type	Tower
Case Form Factor	Mid Tower
Power Supply Included	No
Optimised for	Gaming
80Plus Rated	No
PSU Form Factor	ATX
Illuminated	Yes
L.E.D Fan	ARGB
Max 3.5" Drives	2
Max 2.5" Drives	2
ATX	Yes
Micro-ATX	Yes
ITX	Yes
E-ATX	Yes
Cooler Height	184 mm
Built-in Card Reader	No
USB Type-C Support	Yes
Side Panel Type	Tempered Glass
GPU Length	415 mm
PSU Depth	270 mm
Number of Fans	4 fan(s)
RGB LED Controller Included	No
LED Strip(s) Included	No
Fan Connector	4-pin PWM
Maximum Motherboard Size Supported	E-ATX
RGB Software Type	None
Total 2.5" + 3.5" drive bays	2
Power Requirement (auto)	12 W
USB3.0 ports	1
USB-C ports	1
Low profile expansion	No
Max Supported Radiator Length	360 mm
Create Your Own Gaming PC (CCL)	Yes
Back Connect Support	No
