NZXT H9 Flow RGB Mid Tower Gaming Case White

  • Part Number: CM-H92FW-R1
  • Manufacturer: NZXT
  • Quickfind Code: 106042
  • Stock: In Stock

£128.59 ex. vat
£154.31 inc. vat

Product Features:
  • Condition: New
  • Form Factor E-ATX
  • RGB / LED Colour RGB
  • Main Colour White
  • Side Panel Tempered Glass
+ Read More Information

Share:

Product Description

The H9 Flow is a spacious mid-tower ATX case built for high-performance builds, balancing airflow and aesthetics. Its dual-chamber design improves cooling and cable management, while perforated panels, angled fans, and ample fan and radiator support deliver optimal thermal performance.

Main Features

  • Dual-Chamber Design: Separates main components from the PSU and drives for improved thermal performance and cable management.
  • Optimized Airflow: Perforated steel panels and angled front-right fans ensure efficient cooling for high-performance builds.
  • Pre-Installed Fans: Includes one F420 RGB Core single-frame fan unit in the front-right and one F120Q (CV) fan in the rear. CV = Case Version (3-pin DC)
  • Ten-Fan Capacity: Supports up to nine 140mm fans across the top, front-right, and bottom, plus one 120mm fan in the rear.
  • Panoramic View: Showcase every detail of your build with seamless, wraparound tempered glass paneling.
  • Large Radiators & GPUs: Fits up to a 420mm radiator on the top and front-right, with plenty of clearance for high-end graphics cards.
  • Easy Cable Management: Extra-wide channels, built-in Velcro straps, and tie-down points make cable routing effortless.
  • Back-Connect Ready: Compatible with rear-connecting motherboards like ASUS BTF and MSI Project Zero for a cable-free look.
Technical Specification

NZXT H9 Flow RGB Mid Tower Gaming Case White

Storage

Internal Expansion Bays4 x 2.5"
2 x 2.5"/3.5"

Expansion

Expansion Slots7 x Full Height

Interfaces/Ports

USB Ports1 x USB-C 3.2
2 x USB 3.0
Headphone Ports1 x 3.5mm COMBO Jack
Microphone In PortShared with Headphone

Electrical

Cooling SystemFront: Supports 3 x 140mm or 120mm fans (3 x 140mm ARGB fans included)
Top: Supports 3 x 140mm or 120mm fans
Bottom: Supports 3 x 140mm or 120mm fans
Rear: Supports 1 x 120mm fan (included)
Power SupplyATX Power Supply supported

Physical

Form FactorMid Tower Case
Case ColourWhite
MaterialSGCC Steel
Tempered Glass
Motherboard CompatibilityE-ATX (up to 277mm)
ATX
mATX
Mini-ITX
Width315 mm
Depth481 mm
Height506 mm
Weight12.6 kg

Warranty

Warranty2 Years

Key Features

Max Motherboard Width277 mm
Max Motherboard Height305 mm
Supports AIO CoolerYes
Main ColourWhite
Case TypeTower
Case Form FactorMid Tower
Power Supply IncludedNo
Optimised forGaming
80Plus RatedNo
PSU Form FactorATX
IlluminatedNo
L.E.D FanARGB
Max 3.5" Drives2
Max 2.5" Drives6
ATXYes
Micro-ATXYes
ITXYes
E-ATXYes
Cooler Height165 mm
Built-in Card ReaderNo
USB Type-C SupportYes
Side Panel TypeTempered Glass
GPU Length410 mm
PSU Depth200 mm
Number of Fans4 fan(s)
RGB LED Controller IncludedNo
LED Strip(s) IncludedNo
Fan Connector3-pin DC
Maximum Motherboard Size SupportedE-ATX
RGB Software TypeNone
Total 2.5" + 3.5" drive bays6
Power Requirement (auto)12 W
USB3.0 ports2
USB-C ports1
Low profile expansionNo
Max Supported Radiator Length420 mm
Create Your Own Gaming PC (CCL)No
Back Connect SupportYes

Item Details

ManufacturerNZXT
Manufacturer CodeCM-H92FW-R1
EAN5056547207650
