Smart in spacing
MSI's mainstream MAG series epitomises stability and durability and is built to withstand the most intense gaming sessions. The entire lineup features robust construction with metallic-like hardness and excellent heat dissipation, ensuring stability for all critical gaming components. Built with a unified aesthetic in mind, the design features bold diagonal lines and sharp cut angles—perfectly matching MAG series motherboards, liquid coolers, and power supplies. It brings a cohesive, polished look to your entire PC build.
a unified aesthetic in mindOne bracket, two orientations. A quick 90° rotation allows quick switching between horizontal and vertical GPU installations.
*(Riser cable sold separately).
ATX and Micro-ATX CompatibleEnable a clean layout by routing cables through the rear, simplifying installation and enhancing the aesthetic appeal of any gaming setup.
Dust filter protectionA magnetic dust filter is installed on the bottom of the case, while a removable filter covers the bottom vents - both designed to prevent dust build-up and allow for easy cleaning.
Toolless Removable Glass PanelsScrewless mounting and tool-free removable panel design on both sides allow for greater setup flexibility.
Airflow Optimisation.Increase the number of vents on the sides and front of the case to enhance overall heat dissipation.
Cooling Support• Top: 3 x 120mm / 2 x 140mm
• Front: N/A
• Rear: 1 x 120mm
• Side: 3 x 120mm
• Bottom: 3 x 120mm (Above power shroud)
Pre-installed Fan Type• Rear: 1 x 120 mm ARGB Fan
• Side: 3 x 120 mm ARGB Fan (Reverse Blade Fan)
Radiator Support• Top: 120 / 140 / 240 / 280 / 360mm
• Front: N/A
• Rear: 1 x 120mm
• Side: 120 / 240 / 360mm
MSI MAG PANO 130R PZ ATX Tempered Black White PC Gaming Case
| Core Chassis Specifications | |
|---|---|
| Case Edition | MAG PANO 130R PZ |
| Case Form Factor | Mid Tower |
| Motherboard Form Factor |
|
| Back Connect Compatible | Yes |
| I/O, Bays & Expansion | |
|---|---|
| Front/Side/Top Panel I/O |
|
| Drive Bays | 2 x 3.5" / 3x 2.5" Internal |
| Standard Expansion Slots | 7 |
| Vertical Expansion Slots | |
| Fans & Filters | |
|---|---|
| Fan Bays |
|
| Fans Included | 4 x 120mm w/ Addressable RGB LEDs |
| Fan Controller/Hub | |
| Dust Filters | |
| Liquid Cooling Support | |
|---|---|
| Front Radiator Compatibility | |
| Top Radiator Compatibility | 1 x 120/140/240/280/360mm |
| Bottom Radiator Compatibility | |
| Rear Radiator Compatibility | 1 x 120mm |
| Side Radiator Compatibility | 1 x 120/240/360mm |
| Clearances | |
|---|---|
| Max CPU Cooler Height | 165 mm |
| Max GPU Card Length | 400 mm |
| Cable Routing Space | |
| Side Panels | |
|---|---|
| Window/s | Yes |
| Window Configuration |
|
| Window Construction | Tempered Glass |
| LED Lighting Functionality | |
|---|---|
| LED Lighting | Yes |
| LED Lighting Emitters | Included Addressable LED Fan/s |
| LED Lighting Colour | RGB |
| LED Lighting Support & Control | |
| Power Supply Compatibility | |
|---|---|
| PSU Included | No |
| PSU Wattage (If Included) | |
| PSU 80+ Rating (If Included) | |
| PSU Support | ATX |
| PSU Mounting Location | Bottom Mount, Rear |
| Max PSU Length | 180 mm |
| Chassis Physical Specifications | |
|---|---|
| Colour | Black |
| Chassis Construction Materials | |
| Dimensions | 232 x 490 X 460 (WxHxD mm) |
| Weight | 8.37 kg (Approx) |
| Package Type | Retail |
| Please Note | |
| Additional Information | |
|---|---|
| Model Number | MAG PANO 130R PZ |
| GTIN | 4711377365758 |
