Derived from the O11D EVO, the O11D EVO RGB can be displayed in two modes with just a few simple steps, allowing for a left or right view. It also comes in two color options: Black and White.
The O11D EVO RGB features a 1.5mm thick L-shaped ARGB strip at both the top and bottom of the chassis that can switch between 14 different lighting effects, adjust brightness and color, and sync with the motherboard.
The O11D EVO RGB’s front pillar can now be easily removed, providing a seamless view for showcasing hardware without affecting the case’s structure.
Compared to the O11D EVO, the O11D EVO RGB is slightly larger, which provides higher component compatibility: it supports a 420mm radiator at the top (requires a separate bracket, 360mm radiator at the side/bottom, and 3x140mm fans at all three sides.
Modularity has always been one of the design languages ??of the O11D EVO series, and the O11D EVO RGB is no exception.
At the bottom of the chassis, the I/O module with a wealth of ports, can be relocated to 3 different locations without the use of any tools.
In addition, we have a separate I/O module O11DE-3XV2/O11DE-3WV2 as an optional accessory to meet the needs of the users that require more I/O ports.
The distance between the left-sided and right-sided installation positions reaches 20mm, so users who use EATX motherboards can choose the right-sided installation to avoid the fans from being blocked by the motherboard while gaining more cable management space. Additionally, the O11D EVO RGB features a newly designed vertical corner grommet, making cable management friendlier even when using a large motherboard.
The O11D EVO RGB features two sets of pilot holes at different heights, allowing the users to adjust the installation position of the motherboard to accommodate different builds.
O11D EVO RGB features an improved cable management design, featuring large VELCRO straps near the PSU chamber, dual-layer cable clips that can hold both the bulky and thinner cables, and 15mm of extended space from the rear of the PSU chamber for more cable management room.
O11D EVO RGB comes with the new anti-sag bracket GB-003 with easy height adjustment to support heavy GPUs.
O11D EVO RGB offers multiple easily accessible storage mounting locations that support up to 8 × SSDs or 4 × HDDs + 2 × SSDs.
Lian Li O11 Dynamic EVO RGB Mid Tower Case Black
Storage
| Internal Expansion Bays | Side: 4 x 2.5" or 2 x 3.5" MB Tray: 2 x 2.5" HDD Cage: 2 x 2.5" or 3.5" |
Expansion
| Expansion Slots | 7 x Full Height |
Interfaces/Ports
| USB Ports | 1 x USB-C 3.1 2 x USB 3.0 |
| Headphone Ports | 1 x 3.5mm COMBO Jack |
| Microphone In Port | Shared with Headphone |
Electrical
| Cooling System | Top: Supports 3 x 140mm or 3 x 120mm fans Side: Supports 3 x 140mm or 3 x 120mm fans Bottom: Supports 3 x 140mm or 3 x 120mm fans Rear: Supports 1 x 120mm fan |
| Power Supply | ATX Power Supply supported |
Physical
| Form Factor | Mid Tower Case |
| Case Colour | Black |
| Material | Aluminum Steel Tempered Glass |
| Motherboard Compatibility | E-ATX (up to 280mm) ATX mATX Mini-ITX |
| Width | 290 mm |
| Depth | 478 mm |
| Height | 471 mm |
Warranty
| Warranty | 1 Year |
Key Features
| Max Motherboard Width | 280 mm |
| Max Motherboard Height | 305 mm |
| Supports AIO Cooler | Yes |
| Main Colour | Black |
| Case Type | Tower |
| Case Form Factor | Mid Tower |
| Power Supply Included | No |
| 80Plus Rated | No |
| PSU Form Factor | ATX |
| Illuminated | Yes |
| L.E.D Fan | No LED |
| Max 3.5" Drives | 4 |
| Max 2.5" Drives | 8 |
| ATX | Yes |
| Micro-ATX | Yes |
| ITX | Yes |
| E-ATX | Yes |
| Cooler Height | 167 mm |
| USB Type-C Support | Yes |
| Side Panel Type | Tempered Glass |
| GPU Length | 455 mm |
| PSU Depth | 215 mm |
| RGB LED Controller Included | No |
| LED Strip(s) Included | No |
| Maximum Motherboard Size Supported | E-ATX |
| RGB Software Type | None |
| Total 2.5" + 3.5" drive bays | 8 |
| USB3.0 ports | 2 |
| USB-C ports | 1 |
| Low profile expansion | No |
| Max Supported Radiator Length | 420 mm |
| Create Your Own Gaming PC (CCL) | Yes |
| Back Connect Support | No |
Item Details
| Manufacturer | Lian Li |
| Manufacturer Code | O11DERGBX |
| EAN | 4718466014153 |
