Fractal Design Meshify 2 RGB Case - White

Part Number: FD-C-MES2A-08
Manufacturer: Fractal Design
Quickfind Code: 105542

Stock: In Stock

£139.48 ex. vat
£167.38 inc. vat

Product Features:

Condition: New
Form Factor E-ATX
RGB / LED Colour RGB
Main Colour White
Side Panel Tempered Glass

+ Read More Information

Product Description

The Meshify 2 RGB is a high-performance case with a bold, stealth-inspired aesthetic. Its striking exterior features bolt-free, flush tempered glass, a fully removable top granting excellent interior access, and a front with USB-C, hinged mesh panel and removable nylon filter. The flexible dual-layout interior supports large storage arrays and multi-radiator setups that makes cooling a breeze.

Light and Colour

Comes with 4x Aspect 14 RGB PWM fans pre-installed.

Generous Space

Meshify 2’s roomy internal layout easily accommodates E-ATX motherboards up to 285 mm wide.

Extremely Flexible

Transformable interior design utilizing a movable wall for enhancing custom builds.

Smooth and Sturdy

The Meshify 2 is remarkably robust and comes with an angular asymmetrical style front mesh.

Flexible Dual-Layout Design

There’s more than enough space for your custom water loop with large reservoirs and radiators up to 360 mm in the default Open Layout.

Detachable Front Filter

The front nylon filter can easily be removed from the hinged mesh panel for increased airflow.

Superlative Storage

Convert to Storage Layout and install up to 11 HDDs alongside four dedicated SSDs mounts. (6x SSD/HDD trays, 2x SSD brackets and 1x Multibracket included)

Open and Interchangeable

Remove the entire top to build and route with zero hindrance. Swap in the ventilated panel to add three filtered fan positions.

Smooth Airflow

Four Aspect 14 RGB PWM fans come preinstalled with room to expand up to a total of nine fans.

Easier Front Access

I/O connections are separated from the redesigned front panel to simplify installation and modding.

Versatile Multibracket

The included Multibracket lets you convert any unused fan position to an HDD, SSD or pump mount.

Main Features

Comes with 4x Aspect 14 RGB PWM fans pre-installed
Repositioned front fan mounting sets a wider stage for light and color
Built in RGB controller on the front/top I/O with iconic Fractal Northern Lights effect
Iconic angular mesh design provides filtered airflow with a bold, stealth-inspired aesthetic
Spacious and extensively adaptable dual-layout interior easily accommodates large motherboards up to and including 285 mm E-ATX
Support for radiators up to 360 mm in front, 360 mm up top, or 280 mm in the base in the default Open Layout
Includes 6 HDD/SSD trays, 2 SSD brackets, and 1 universal Multibracket for mounting up to 9 drives
Expandable to 11 trays and 4 SSD brackets with 3 Multibrackets installed in the top and bottom for a max of up to 18 drives in Storage Layout
Chassis opens up to fully expose the case interior on three sides for totally unhindered installation and cable routing
Front nylon filter that can be removed for increased airflow
Front panel with hinged removable mesh and tether-free bezel for easier access to front fan mounts
Three front USB ports including one USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps
Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans directly in line with cable channels along the edge of the case
Outstanding cooling capacity with a total of nine 120/140 mm fan mounts and four preinstalled Aspect 14 RGB PWM fans
Detachable PSU cable shield and integrated cable guides with cable ties further simplify cable management behind the board
Versatile Multibracket that converts any unused fan position to an HDD, SSD or pump mount
Bridgeless expansion slots ensure obstruction-free connections and allow for a more centered vertical GPU installation via the new Flex B-20 PCIe riser (sold separately)
Two vertical GPU slots for use with the Flex VRC-25 PCIe riser, available separately
Easy-to-clean high airflow nylon filters on the front, top and base with full PSU coverage and convenient front access
Ventilated PSU shroud with two-part removable cover for optimal cable concealment and front radiator support
Tool-less, top-latching side panels allow quick access while preventing accidental drops

Technical Specification

Fractal Design Meshify 2 RGB Case - White

User Controls

Power
LED Control

Storage

Internal Expansion Bays

2 x 2.5"
6 x 2.5"/3.5"

Expansion

Expansion Slots

7 x Full Height
2 x Vertical

Interfaces/Ports

USB Ports	1 x USB-C 3.1 2 x USB 3.0
Headphone Ports	1 x 3.5mm Jack
Microphone In Port	1 x 3.5mm Jack

Electrical

Cooling System	Front: Supports 3 x 140mm or 120mm fans (3 x 140mm ARGB LED fans included) Top: Supports 3 x 140mm or 120mm fans Rear: Supports 1 x 140mm or 120mm fan (140mm ARGB LED fan included) Bottom: Supports 2 x 140mm or 120mm fans
Power Supply	ATX Power Supply supported

Physical

Form Factor	Mid Tower Case
Case Colour	White
Material	Steel Tempered Glass
Motherboard Compatibility	E-ATX (max 285mm) ATX MicroATX Mini-ITX
In The Box	Case User Manual Accessory Boxes
Width	240 mm
Depth	542 mm
Height	474 mm
Weight	11.1 kg

Warranty

2 Years

Key Features

Main Colour	White
Case Type	Tower
USB 3.0 Support	Yes
Case Form Factor	Mid Tower
Power Supply Included	No
80Plus Rated	No
PSU Form Factor	ATX
Illuminated	No
L.E.D Fan	ARGB
Max 3.5" Drives	6
Max 2.5" Drives	2
ATX	Yes
Micro-ATX	Yes
ITX	Yes
E-ATX	Yes
Cooler Height	185 mm
Built-in Card Reader	No
USB Type-C Support	Yes
Front HDMI	No
Side Panel Type	Tempered Glass
GPU Length	450 mm
PSU Depth	250 mm
Front Audio Type	Separate
Number of Fans	4 fan(s)
LED Controller Included	Yes
Maximum Motherboard Size Supported	E-ATX
