Fractal Design Meshify 2 Mini Case Black

Part Number: FD-C-MES2M-01
Manufacturer: Fractal Design
Quickfind Code: 105527

Stock: Out Stock

Contact for availability

Product Features:

Condition: New
Form Factor mATX
Main Colour Black
Side Panel Tempered Glass

+ Read More Information

Product Description

The Meshify 2 Mini offers mATX aficionados an excellent combination of airflow can flexibility for their favorite form-factor. The bold exterior design with asymmetric angular mesh front is complemented by a flush TG panel and a fully removable top. It is a textbook example of what you should expect from a modern mATX case when it comes to flexibility and ease of use.

Main Features

Iconic angular mesh front provides filtered airflow with a bold, stealth-inspired aesthetic
Compact yet roomy interior makes the most of mATX with high space efficiency and robust component support
Open interior layout creates a smooth airflow path from front intake to rear exhaust
Room for GPUs up to 306 mm long including front fans with 331 mm total space
Seamlessly integrated TG panel with steel frame support and bolt-free top-latching mechanism
Fully removable top panel and a top fan bracket that opens to provide excellent interior access and easy cable routing
Double layered front filter with detachable nylon for increased airflow
Three front USB ports including one USB 3.1 Gen 2 Type-C with fast charging and speeds up to 10Gbps
Front panel design with hinged removable mesh filter and tether-free bezel for easier access to front fan mounts
Flexible storage options supporting two 2.5"/3.5" drives and up to four SSDs (two SSD brackets included)
Install up to 7x 120 mm or 4x 140 mm fans (1x 120 mm and 1x 140 mm Dynamic X2 fans included)
Easy-to-clean filters on the front, top and base with full PSU coverage and convenient front access
Bridgeless PCI expansion slots ensure obstruction-free connections for easier installation and hookup
Ventilated PSU shroud with two-part removable cover for optimal cable concealment and front radiator support
Integrated cable guides with velcro straps further simplify cable management behind the board

Technical Specification

Fractal Design Meshify 2 Mini Case Black

User Controls

Power

Storage

Internal Expansion Bays

2 x 2.5"
2 x 2.5"/3.5"

Expansion

Expansion Slots

4 x Full Height

Interfaces/Ports

USB Ports	1 x USB-C 3.1 2 x USB 3.0 2 x USB 2.0
Headphone Ports	1 x 3.5mm Jack
Microphone In Port	1 x 3.5mm Jack

Electrical

Cooling System	Front: Supports 2 x 140mm or 3 x 120mm fans (1 x 140mm fan included) Top: Supports 2 x 140mm or 120mm fans Rear: Supports 1 x 120mm fan (included)
Power Supply	ATX Power Supply

Physical

Form Factor	Mid Tower Case
Case Colour	Black
Motherboard Compatibility	MicroATX Mini-ITX
In The Box	Case Accessory Box User Manual
Width	205 mm
Depth	396 mm
Height	406 mm
Weight	6.62 kg

Warranty

2 Years

Key Features

Firewire
Power	W
Laptop Size Range	ins
Main Colour	Black
External Expansion Bays
Case Type	Tower
USB 3.0 Support	Yes
Case Form Factor	Mid Tower
Power Supply Included	No
Optimised for
Modular Cables
80Plus Rated	No
Bag Size
PSU Form Factor	ATX
Display Model in Showroom
Illuminated	No
e-SATA
L.E.D Fan	No LED
Laptop Size
Max 3.5" Drives	2
Max 2.5" Drives	4
ATX
Micro-ATX	Yes
ITX	Yes
E-ATX
XL-ATX
Mini PC
Cooler Height	167 mm
Built-in Card Reader	No
USB Type-C Support	Yes
Front HDMI	No
Side Panel Type	Tempered Glass
GPU Length	306 mm
PSU Depth	165 mm
Memory Speed	MHz
Card Reader Type
Front Audio Type	Separate
Number of Fans	2 fan(s)
LED Controller Included	No
LED Strip(s) Included
Maximum Motherboard Size Supported	Micro-ATX
RGB Software Type
Total 2.5" + 3.5" drive bays	4
Power Requirement (auto)	6 W
USB2.0 ports	2
USB3.0 ports	2
USB-C ports	1
Low profile expansion	No
