CiT Classic Midi Case - Black
- Part Number: CIT CLASSIC MIDI
- Manufacturer: CiT
- Quickfind Code: 105305
- Stock: In Stock
£34.12 ex. vat
£40.94 inc. vat
Product Features:
- Condition: New
- Form Factor ATX
- Main Colour Black
- Side Panel Solid
Share:
For sales and support
Call:0161 480 8800
Product Description
The CiT Classic Midi is a compact ATX chassis design that supports both Micro ATX and ATX motherboards and is aimed at business and home office solutions. Equipped with 2 x USB 3.0 and 2 x USB 2.0 ports, the Classic Midi also supports a rear 80mm fan.
Power Supply
A basic 500W power supply is pre-installed, with the following specifications and cables:
PSU Rail Outputs
- +3.3V: 28A
- +5V: 30A
- +12V: 27A
- -12V: 0.3A
- +5VSB: 2.5A
Connectors
- 1 x 20+4-pin ATX
- 1 x 4-pin CPU
- 2 x SATA
- 2 x Molex
- 1 x FDD
Clearances
- Max GPU Length: 320mm
- Max CPU Cooler Height: 145mm
Main Features
- Storage Capacity - Case supports up to 3 x HDD's (2.5" or 3.5").
- Front I/O Ports - 2 x USB 2.0, 2 x USB 3.0 and HD Audio.
- VGA Support - Can take VGA cards up to 320mm in length.
- Motherboards - Supports ATX or Micro ATX motherboards.
- Side Panel - Intel TAC2.0 side panel vent hole design.
Technical Specification
CiT Classic Midi Case - Black
User Controls
| User Controls | Power Reset |
Storage
| External Expansion Bays | 1 x 5.25" 1 x 3.5" |
| Internal Expansion Bays | 2 x 3.5" 1 x 2.5" |
Expansion
| Expansion Slots | 7 x Full Height |
Interfaces/Ports
| USB Ports | 2 x USB 3.0 2 x USB 2.0 |
| Headphone Ports | 1 x 3.5mm Jack |
| Microphone In Port | 1 x 3.5mm Jack |
Electrical
| Power | 500 W |
| Cooling System | Rear: Supports 1 x 80mm fan (included) Side: Supports 2 x 80mm, 92mm or 120mm fans |
| Power Supply | ATX Power Supply pre-installed |
Physical
| Form Factor | Mid Tower Case |
| Case Colour | Black |
| Material | 0.45mm Metal Plastic |
| LED Status Indicators | Power HDD |
| Motherboard Compatibility | ATX Micro-ATX Mini-ITX |
| In The Box | Case Screws |
| Width | 175 mm |
| Depth | 376 mm |
| Height | 405 mm |
| Weight | 3.6 kg |
Key Features
| Firewire | No |
| Main Colour | Black |
| Case Type | Tower |
| USB 3.0 Support | Yes |
| Case Form Factor | Mid Tower |
| Power Supply Included | Yes |
| Optimised for | Home |
| PSU Form Factor | ATX |
| Display Model in Showroom | No |
| e-SATA | No |
| L.E.D Fan | No LED |
| Internal 3.5" Bay | 2 |
| External 5.25" Bay | 1 |
| Internal 2.5" Bay | 1 |
| ATX | Yes |
| Micro-ATX | No |
| ITX | No |
| E-ATX | No |
| XL-ATX | No |
| Cooler Height | 145 mm |
| Built-in Card Reader | No |
| USB Type-C Support | No |
| Front HDMI | No |
| Side Panel Type | Solid |
| GPU Length | 320 mm |
| Front Audio Type | Separate |
| Maximum Motherboard Size Supported | ATX |
Warranty
| Warranty | 1 Year |
Item Details
| Manufacturer | CiT |
| Manufacturer Code | CIT CLASSIC MIDI |
| EAN | 5055492406118 |
| Condition | New |
