The Antec FLUX M is a compact MicroATX case featuring the F-LUX Platform (Flow Luxury) for excellent airflow with 6 pre-installed high-performance PWM fans. Its multi-directional vent design with extensive front, bottom, and top mesh panels ensures enhanced GPU cooling. The case supports up to 360mm water cooling, has a front-mounted PSU chamber for improved airflow, tool-free panels, and robust cable management. It accommodates GPUs up to 405mm and CPU coolers up to 175mm tall, blending airflow and style efficiently.?
The F-LUX Platform, short for Flow Luxury, incorporates an advanced case structure that prioritises top-tier airflow and includes six pre-installed fans, allowing for superior cooling performance specifically for high-powered GPUs.?
This multi-directional vent design makes use of wide air intake openings on the front and bottom, supplemented by upper vents and a large mesh area up front, resulting in a dedicated Antec Flux airflow path for optimal cooling.
The large bottom intake boosts airflow significantly with approximately 20mm space between the bottom fans and the GPU. This spacing enables reverse fans to efficiently and directly cool the GPU, enhancing thermal performance in a focused manner.
Includes a support bracket designed for compatibility with high-performance graphics cards, offering sturdy and adjustable support to prevent GPU sag and enhance stability during operation. This bracket accommodates various GPU sizes and mounting orientations to ensure optimal fit and cooling efficiency.?
Motherboard support: Micro-ATX, ITX
CPU cooler max height: = 175mm
GPU max length: = 405mm
Power Supply max length (w/o cable): = 160mm
3.5"/2.5": 2x/2x
Antec Antec FLUX M Micro Tower Gaming Case Black
Expansion
| Expansion Slots | 5 |
Interfaces/Ports
| USB Ports | USB3.0 x 1, Type-C 3.2 Gen 2 (10 Gbps) x 1 |
| Headphone Ports | Headphone/Mic Combo Jack |
Physical
| Form Factor | mATX |
| Case Colour | Black |
| Material | Steel + Plastic / 3mm Tempered Glass |
| Motherboard Compatibility | mATX / ITX |
| Width | 247mm |
| Depth | 459mm |
| Height | 365mm |
| Weight | 7.41kg Gross Weight |
Warranty
| Warranty | 2 Years |
Key Features
| Max Motherboard Width | 244 mm |
| Max Motherboard Height | 244 mm |
| Supports AIO Cooler | Yes |
| Main Colour | Black |
| Case Type | Gaming |
| Case Form Factor | Micro Tower |
| Power Supply Included | No |
| Optimised for | Gaming |
| 80Plus Rated | No |
| PSU Form Factor | ATX |
| Max 3.5" Drives | 2 |
| Max 2.5" Drives | 2 |
| ATX | No |
| Micro-ATX | Yes |
| ITX | No |
| E-ATX | No |
| Cooler Height | 175 mm |
| USB Type-C Support | Yes |
| Side Panel Type | Tempered Glass |
| GPU Length | 405 mm |
| PSU Depth | 160 mm |
| Number of Fans | 5 fan(s) |
| Fan Connector | 4-pin PWM |
| Maximum Motherboard Size Supported | mATX |
| Total 2.5" + 3.5" drive bays | 2 |
| Power Requirement (auto) | 15 W |
| USB3.0 ports | 1 |
| USB-C ports | 1 |
| Max Supported Radiator Length | 360 mm |
| Back Connect Support | No |
Item Details
| Manufacturer | Antec |
| Manufacturer Code | 0-761345-10253-7 |
| EAN | 0761345102537 |
